4. CONTROLS

L

T1

T2

T3

T4

S1

Key

Function

LED

L

Short  press:  the  lights  alternate  between  high  intensity,  medium  intensity  (if

present) and off.

If  there  is  an  induction  cooktop  coupled  with  the  hood  and  the  hood  is  off,  as

soon  as  the  induction  cooktop  is  turned  on,  the  hood  lights  automatically  turn  on

at the maximum intensity.

-

Delay Function

Long press:
Activates/Deactivates the Delay function (automatic shutdown of the Motor and of

the lighting delayed by 30').
Cannot be activated with Intensive or 24h function.

Flashing

K-Link coupling

Before starting the procedure follow the specific instructions of the manuals of the

devices to be coupled.

Long press when all loads are off (Motor+Light):
starts the pairing procedure between the hood and compatible K-Link devices (in-

duction cooktop or remote control). Up to 3 induction cooktops can be paired and

only  one  remote  control.  See  the  manual  of  the  devices  for  details  of  the  opera-

tions that need to be performed on these.

The coupling procedure takes 2 minutes. If no devices are recognised within this

time check that you have previously activated the procedure for the devices to be

coupled. The maximum number of linkable devices may have been reached.

LEDs T1 and T2 flashing:
coupling in progress.

Upon  successful  completion

of  the  procedure  LEDs  T1

and  T2  will  light  up  for  2

seconds.

T1

Turns the motor on/off at the first speed.

Fixed

Long press:
Activates/Deactivates the

Activated Carbon Filters alarm

.

Note: perform the operation with the lights on only (motor off).

All LEDs flash twice:
alarm activated.

All LEDs lit for 1 second:
alarm deactivated.

K-Link uncoupling

Long press when all loads are off (Motor+Light):
starts  the  procedure  for  the  cancellation  of  all  compatible  K-Link  devices  previ-

ously paired with the K-Link Coupling function.

Upon  successful  completion

of  the  procedure  LEDs  T1

and T2 flash 5 times.

T2

Turns the motor on/off at the second speed.

Fixed

24h Function

Long press:
Activates/Deactivates  the  motor  in  the  24h  Air  Exchange  mode,  a  speed  that  al-

lows suction of 10 minutes every hour, for a 24-hour cycle.
Cannot be activated if the Intensive or Delay modes are active.

Flashing

6
