5

Controls

Button Function

Led

L

Turns the lights ON/OFF at maximum strength.

-

T1

Turns the motor on/off at speed one.

-

Delay Function:

Press and hold the button for approx. 3 seconds to Activate/Deactivate the

Delay function (automatic switching off of the Motor, the Fans and the Lighting

with a 30’ delay).

Cannot be enabled when Intensive or 24H are on.

Flashing

T2

Turns the Motor on at speed two.

-

Press and hold the button for approximately 5 seconds, with all the loads

turned off (Motor and Lights), to turn the Activated Charcoal Filter alarm on.

The  relevant  LED  flashes  twice  to  confirm.

To turn the alarm off, press the button again and hold for at least 5 seconds.

The  relevant  LED  flashes  once.

Flashing

T3

Turns the Motor on at speed three.

-

Press and hold the button for approximately 3 seconds, with all the loads

turned off (Motor and Lights), to reset the Filter saturation alarm. The

LED

S1

  flashes  three  times.

Flashing

T4

Turns the Motor on at

INTENSIVE

.

This speed is timed to run for 6 minutes. At the end of this time, the

system returns automatically to the speed that was set before. If it is

activated with the motor turned off, the hood will switch to OFF at the

end of the time.

-

Press and hold for 5 seconds to enable the remote control, indicated by

the  LED  flashing  twice.

Press and hold for 5 seconds to disable the remote control, indicated by

the  LED  flashing  just  once.

Flashing

S1

Signals the Metal Grease Filter saturation alarm, indicating that it is

necessary  to  wash  the  filters.  The  alarm  is  triggered  after  the  Hood  has

been in operation for 100 working hours.

Fixed

Signals  the Activated  Charcoal  Filter  saturation  alarm.  The  filter  must  be

changed after the Hood has been working for 200 hours.

Flashing
