Operation

Use the high suction speed in cases of concentrated kitchen
vapours.  It is recommended that the cooker hood suction is
switched on for 5 minutes prior to cooking and to leave in
operation during cooking and for another 15 minutes
approximately after terminating cooking.

To select the functions of the hood just touch the commands.


Light key ON/OFF

Intensive speed selection key

 (suction power) -

duration 5 minutes - press again to return to
previous setting.

High-speed selection key

(suction power).

Medium-speed selection key

 (suction power) -

when flashing it indicates the need to wash or
replace the carbon filter. This signal is normally
deactivated. To activate the alarm, disable the
electronic by pressing the

0

 button for 3 seconds.

Next, simultaneously press buttons

1

 and

2

for 3

seconds; at first, only button

1

will flash, then both

buttons

1

 and

2

 will flash to indicate activation.

Repeat the procedure to deactivate the alarm; at
first buttons

1

 and

2

 will flash and subsequently

only button

1

 to indicate deactivation.

Low-speed selection key

 (suction power) – when

flashing it indicates the need to wash the fats filter.

Motor key OFF

 (stand by) – excludes the

electronics – reset wash/replace filters signals.

MOTOR OFF

Press briefly to switch the motor off.

RESET FILTERS SIGNALS

In functioning mode, after carrying out filter
maintenance, press the key until hearing the sound
signal. The flashing LED

1

(grease filter) or

2

(carbon filter) stops flashing.

EXCLUDING THE ELECTRONICS

Press the key for 3 seconds. The hood command
electronics will be excluded.
This function can be useful during the product
cleaning operations.
Just repeat the operation to reinsert the
electronics.


If the hood fails to operate correctly, briefly disconnect it from
the mains power supply for almost 5 sec. by pulling out the
plug. Then plug it in again and try once more before
contacting the Technical Assistance Service.

Maintenance

ATTENTION!

Before performing any maintenance operation,

isolate the hood from the electrical supply by switching off at
the connector and removing the connector fuse.
Or if the appliance has been connected through a plug and
socket, then the plug must be removed from the socket.

Cleaning

The cooker hood should be cleaned regularly (at least with the
same frequency with which you carry out maintenance of the
fat filters) internally and externally.  Clean using the cloth
dampened with neutral liquid detergent. Do not use abrasive
products.

DO NOT USE ALCOHOL!

WARNING:

Failure to carry out the basic cleaning

recommendations of the cooker hood and replacement of the
filters may cause fire risks.
Therefore, we recommend observing these instructions.
The manufacturer declines all responsibility for any damage to
the motor or any fire damage linked to inappropriate
maintenance or failure to observe the above safety
recommendations.

Grease filter

Fig. 19-25
Traps cooking grease particles.

This must be cleaned once a month (or when the filter
saturation indication system – if envisaged on the model in
possession – indicates this necessity)  using non aggressive
detergents, either by hand or in the dishwasher, which must
be set to a low temperature and a short cycle.
When washed in a dishwasher, the grease filter may discolour
slightly, but this does not affect its filtering capacity.
To remove the grease filter, pull the spring release handle.

Charcoal filter (filter version only)

Fig. 23
It absorbs unpleasant odours caused by cooking.

The charcoal filter can be washed every two months (or when
the filter saturation signal system - if present on your model -

shows such need) in hot water and suitable detergents or in
the dishwasher at 65°C (in this case run a complete wash
cycle with no dishes inside).
Remove excess water without damaging the filter and then put
the filter back in the oven for 10 minutes at 100°C to dry it
definitively.
Replace the pad every 3 years and every time the cloth is
damaged.

Replacing lamps

The hood is equipped with a lighting system based on LED
technology.
The LEDs guarantee an optimum lighting, a duration up to 10
times as long as the traditional lamps and allow to save 90%
electrical energy.

For replacement, contact the technical service.
