20

Operation

Use the high suction speed in cases of concentrated kitchen
vapours.  It is recommended that the cooker hood suction is
switched on for 5 minutes prior to cooking and to leave in
operation during cooking and for another 15 minutes
approximately after terminating cooking.

To select the functions of the hood just touch the commands.


Light key ON/OFF

Intensive speed selection key

(suction

power) - duration 5 minutes - press again to
return to previous setting.

High-speed selection key

(suction power).

Medium-speed selection key

 (suction power)

- when flashing it indicates the need to wash or
replace the carbon filter. This signal is normally
deactivated. To activate the alarm, disable the
electronic by pressing the

0

button for 3

seconds.
Next, simultaneously press buttons

1

 and

2

for

3 seconds; at first, only button

1

will flash, then

both buttons

1

 and

2

 will flash to indicate

activation. Repeat the procedure to deactivate
the alarm; at first buttons

1

 and

2

will flash and

subsequently only button

1

to indicate

deactivation.

Low-speed selection key

 (suction power) –

when flashing it indicates the need to wash the
fats filter.

Motor key OFF

 (stand by) – excludes the

electronics – reset wash/replace filters signals.

MOTOR OFF

Press briefly to switch the motor off.

RESET FILTERS SIGNALS

In functioning mode, after carrying out filter
maintenance, press the key until hearing the
sound signal. The flashing LED

1

(grease filter)

or

2

(carbon filter) stops flashing.

EXCLUDING THE ELECTRONICS

Press the key for 3 seconds. The hood
command electronics will be excluded.
This function can be useful during the product
cleaning operations.
Just repeat the operation to reinsert the
electronics.


If the hood fails to operate correctly, briefly disconnect it from
the mains power supply for almost 5 sec. by pulling out the

plug. Then plug it in again and try once more before
contacting the Technical Assistance Service.


Note

: with  the hood ON, the outer ring of the hood retreats

("open" position) to allow the passage of air.
Turning off the hood 'the ring returns to rest position ("closed"
position).

Note:

 The perimeter suction panel should always be left

closed and should only be opened when maintenance is
performed.
A special device prevents accidental movement of the outer
ring with the perimeter suction panel open.

Cleaning mode:

Exclude electronic components (see "

EXCLUDING THE

ELECTRONICS

"

in the previous paragraph..

Press

 and

 for 3 seconds, buttons start flashing to

indicate that you are in "

Cleaning mode

" and it is therefore

possible to perform filters’ maintenance or access the motor
compartment.

Press the button

 for 3 seconds to exit the "

Cleaning

mode

" function.
