EN - Instruction on mounting and use

Closely follow the instructions set out in this manual.

All responsibility,

for any eventual inconveniences, damages or fires caused by not complying

with the instructions in this manual, is declined. The hood is conceived for

the suction of cooking fumes and steam and is destined only for domestic

use.

Note:

the elements marked with the symbol “(*)” are optional

accessories supplied only with some models or elements to purchase, not

supplied.

  Caution

WARNING!

Do not connect the appliance to the mains until the installation is

fully complete.

Before any cleaning or maintenance operation, disconnect hood from the

mains by removing the plug or disconnecting the mains electrical supply.

Always wear work gloves for all installation and maintenance operations.

The appliance is not intended for use by children or persons with impaired

physical, sensorial or mental faculties, or if lacking in experience or

knowledge, unless they are under supervision or have been trained in the

use of the appliance by a person responsible for their safety. This appliance

is designed to be operated by adults, children should be monitored to ensure

that they do not play with the appliance. This appliance is designed to be

operated by adults.  Children should not be allowed to tamper with the

controls or play with the appliance. Never use the hood without effectively

mounted grating! The hood must NEVER be used as a support surface

unless specifically indicated. The premises where the appliance is installed

must be sufficiently ventilated, when the kitchen hood is used together with

other gas combustion devices or other fuels.  The ducting system for this

appliance must not be connected to any existing ventilation system which is

being used for any other purpose such as discharging exhaust fumes from

appliances burning gas or other fuels.  The flaming of foods beneath the

hood itself is severely prohibited. The use of exposed flames is detrimental

to the filters and may cause a fire risk, and must therefore be avoided in all

circumstances.  Any frying must be done with care in order to make sure that

the oil does not overheat and ignite. Accessible parts of the hood may

became hot when used with cooking appliance. With regards to the technical

and safety measures to be adopted for fume discharging it is important to

closely follow the regulations provided by the local authorities.  The hood

must be regularly cleaned on both the inside and outside (AT LEAST ONCE

A MONTH). This must be completed in accordance with the maintenance

instructions provided in this manual). Failure to follow the instructions

provided in this user guide regarding the cleaning of the hood and filters will

lead to the risk of fires. Do not use or leave the hood without the lamp

correctly mounted due to the possible risk of electric shocks. We will not

accept any responsibility for any faults, damage or fires caused to the

appliance as a result of the non-observance of the instructions included in

this manual. This appliance is marked according to the European directive

2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). By

ensuring this product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which could

otherwise be caused by inappropriate waste handling of this product.

The symbol

 on the product, or on the documents accompanying the

product, indicates that this appliance may not be treated as household
waste. Instead it should be taken to the appropriate collection point for the
recycling of electrical and electronic equipment. Disposal must be carried out
in accordance with local environmental regulations for waste disposal.
For further detailed information regarding the process, collection and
recycling of this product, please contact the appropriate department of your
local authorities or the local department for household waste or the shop
where you purchased this product.

Additional Installation Specifications:

Use only the fixing screws supplied with the product for installation.  Use the
correct length screws which are identified in the Installation Guide

WARNING!

Failure to install the screws or fixing device in accordance with

these instructions may result in electrical hazards.


Use

The hood is designed to be used either for exhausting

 or filter

version

.

Installation

The minimum distance between the supporting surface for the cooking
equipment on the hob and the lowest part of the range hood must be not
less than 65cm from electric cookers and 75cm from gas or mixed cookers.
If the instructions for installation for the gas hob specify a greater distance,
this must be adhered to. The mains power supply must correspond to the
rating indicated on the plate situated inside the hood. If provided with a plug
connect the hood to a socket in compliance with current regulations and

positioned in an accessible area, after installation. If it not fitted with a plug
(direct mains connection) or if the plug is not located in an accessible area,
after installation,  apply a double pole switch in accordance with standards
which assures the complete disconnection of the mains under conditions
relating to over-current category III, in accordance with installation
instructions.

Warning!

 Before re-connecting the hood circuit to the mains

supply and checking the efficient function, always check that the mains cable
is correctly assembled.


Operation

The hood is fitted with a control panel with aspiration speed selection control
and a light switch to control cooking area lights.
Use the high suction speed in cases of concentrated kitchen vapours.  It is
recommended that the cooker hood suction is switched on for 5 minutes
prior to cooking and to leave in operation during cooking and for another 15
minutes approximately after terminating cooking.


Maintenance

ATTENTION!

Before performing any maintenance operation, isolate the

hood from the electrical supply by switching off at the connector and
removing the connector fuse.
Or if the appliance has been connected through a plug and socket, then the
plug must be removed from the socket.
The cooker hood should be cleaned regularly (at least with the same
frequency with which you carry out maintenance of the fat filters) internally
and externally.  Clean using the cloth dampened with neutral liquid
detergent. Do not use abrasive products.

DO NOT USE ALCOHOL!

WARNING:

Failure to carry out the basic cleaning recommendations of the

cooker hood and replacement of the filters may cause fire risks.
Therefore, we recommend observing these instructions.
The manufacturer declines all responsibility for any damage to the motor or
any fire damage linked to inappropriate maintenance or failure to observe
the above safety recommendations.


Grease filter
Fig. 17-19
The grease filter

 must be cleaned once a month using non aggressive

detergents, either by hand or in the dishwasher, which must be set to a low
temperature and a short cycle.  When washed in a dishwasher, the grease
filter may discolour slightly, but this does not affect its filtering capacity.


Charcoal filter (filter version only)
Fig. 18

The saturation of the

charcoal filter

 occurs after more or less prolonged

use, depending on the type of cooking and the regularity of cleaning of the
grease filter.
In any case it is necessary to replace the cartridge at least every four

mounths.
The charcoal filter may NOT be washed or regenerated.


Replacing lamps
Fig. 20

Disconnect the hood from the electricity.

Warning!

Prior to touching the light bulbs ensure they are cooled down.

Replace with a new 12 Volt, 20 Watt (Maximum) halogen light made for a G-
4 base SUITABLE FOR USE IN OPEN LUMINAIRES.  Follow package

directions and do not touch new light with bare hands.
