EN - Instruction on mounting and use

Closely follow the instructions set out in this manual.

All responsibility,

for any eventual inconveniences, damages or fires caused by not complying
with the instructions in this manual, is declined. The hood is conceived for
the suction of cooking fumes and steam and is destined only for domestic
use.

Note:

the elements marked with the symbol “(*)” are optional

accessories supplied only with some models or elements to purchase, not
supplied.


  Caution

WARNING!

Do not connect the appliance to the mains until the installation is

fully complete.  Before any cleaning or maintenance operation, disconnect

hood from the mains by removing the plug or disconnecting the mains

electrical supply.  Always wear work gloves for all installation and

maintenance operations. The appliance is not intended for use by children or

persons with impaired physical, sensorial or mental faculties, or if lacking in

experience or knowledge, unless they are under supervision or have been

trained in the use of the appliance by a person responsible for their safety.

This appliance is designed to be operated by adults, children should be

monitored to ensure that they do not play with the appliance. This appliance

is designed to be operated by adults.  Children should not be allowed to

tamper with the controls or play with the appliance. Never use the hood

without effectively mounted grating! The hood must NEVER be used as a

support surface unless specifically indicated. The premises where the

appliance is installed must be sufficiently ventilated, when the kitchen hood

is used together with other gas combustion devices or other fuels.  The

ducting system for this appliance must not be connected to any existing

ventilation system which is being used for any other purpose such as

discharging exhaust fumes from appliances burning gas or other fuels.  The

flaming of foods beneath the hood itself is severely prohibited. The use of

exposed flames is detrimental to the filters and may cause a fire risk, and

must therefore be avoided in all circumstances.  Any frying must be done

with care in order to make sure that the oil does not overheat and ignite.

Accessible parts of the hood may became hot when used with cooking

appliance. With regards to the technical and safety measures to be adopted

for fume discharging it is important to closely follow the regulations provided

by the local authorities. The hood must be regularly cleaned on both the

inside and outside (AT LEAST ONCE A MONTH). This must be completed in

accordance with the maintenance instructions provided in this manual).

Failure to follow the instructions provided in this user guide regarding the

cleaning of the hood and filters will lead to the risk of fires. Do not use or

leave the hood without the lamp correctly mounted due to the possible risk of

electric shocks. We will not accept any responsibility for any faults, damage

or fires caused to the appliance as a result of the non-observance of the

instructions included in this manual. This appliance is marked according to

the European directive 2002/96/EC on Waste Electrical and Electronic

Equipment (WEEE). By ensuring this product is disposed of correctly, you

will help prevent potential negative consequences for the environment and

human health, which could otherwise be caused by inappropriate waste

handling of this product.

The symbol

 on the product, or on the documents accompanying the

product, indicates that this appliance may not be treated as household
waste. Instead it should be taken to the appropriate collection point for the
recycling of electrical and electronic equipment. Disposal must be carried out
in accordance with local environmental regulations for waste disposal. For
further detailed information regarding the process, collection and recycling of
this product, please contact the appropriate department of your local
authorities or the local department for household waste or the shop where

you purchased this product.

Additional Installation Specifications:

Use

only the fixing screws supplied with the product for installation.  Use the
correct length screws which are identified in the Installation Guide

WARNING!

Failure to install the screws or fixing device in accordance with

these instructions may result in electrical hazards.


Use

The hood is designed to be used either for exhausting

 or filter

version

.

Installation

The minimum distance between the supporting surface for the cooking
equipment on the hob and the lowest part of the range hood must be not
less than

50

cm from electric cookers and 65cm from gas or mixed cookers.

If the instructions for installation for the gas hob specify a greater distance,
this must be adhered to. The mains power supply must correspond to the
rating indicated on the plate situated inside the hood. If provided with a plug
connect the hood to a socket in compliance with current regulations and

positioned in an accessible area, after installation. If it not fitted with a plug
(direct mains connection) or if the plug is not located in an accessible area,
after installation,  apply a double pole switch in accordance with standards
which assures the complete disconnection of the mains under conditions
relating to over-current category III, in accordance with installation
instructions.

Warning!

 Before re-connecting the hood circuit to the mains supply and

checking the efficient function, always check that the mains cable is correctly
assembled.


Operation

The hood is fitted with a control panel with aspiration speed selection control

and a light switch to control cooking area lights. Use the high suction speed

in cases of concentrated kitchen vapours.  It is recommended that the

cooker hood suction is switched on for 5 minutes prior to cooking and to

leave in operation during cooking and for another 15 minutes approximately

after terminating cooking.

Maintenance
ATTENTION!

Before performing any maintenance operation, isolate the

hood from the electrical supply by switching off at the connector and
removing the connector fuse.  Or if the appliance has been connected
through a plug and socket, then the plug must be removed from the socket.
The cooker hood should be cleaned regularly (at least with the same
frequency with which you carry out maintenance of the fat filters) internally
and externally.  Clean using the cloth dampened with neutral liquid
detergent. Do not use abrasive products.

DO NOT USE ALCOHOL!

WARNING:

Failure to carry out the basic cleaning recommendations of the

cooker hood and replacement of the filters may cause fire risks.

Therefore, we recommend observing these instructions. The manufacturer
declines all responsibility for any damage to the motor or any fire damage
linked to inappropriate maintenance or failure to observe the above safety
recommendations.


Grease filter - Fig. 3-5-7

If situated inside the support grill, it may be one of the following types:

Paper filter

 must be replaced once a month or if colouring appears on

upper side, in such cases the colouring is evident through the grill openings.

Metallic filter

must be cleaned once a month, with non abrasive detergents,

by hand or in dishwasher on low temperature and short cycle.
When washed in a dishwasher, the grease filter may discolour slightly, but
this does not affect its filtering capacity.


Charcoal filter (filter version only) - Fig. 7

The saturation of the

charcoal filter

 occurs after more or less prolonged

use, depending on the type of cooking and the regularity of cleaning of the
grease filter. In any case it is necessary to replace the cartridge at least
every four mounths. The charcoal filter may NOT be washed or regenerated.

Replacing lamps
Fig. 8

Disconnect the hood from the electricity.

Warning!

Prior to touching the light bulbs ensure they are cooled down.

Replace with a new 12 Volt, 20 Watt (Maximum) halogen light made for a G-
4 base SUITABLE FOR USE IN OPEN LUMINAIRES.  Follow package
directions and do not touch new light with bare hands.
