17

Operation

Use the high suction speed in cases of concentrated kitchen
vapours.  It is recommended that the cooker hood suction is
switched on for 5 minutes prior to cooking and to leave in
operation during cooking and for another 15 minutes
approximately after terminating cooking.
Always fully open the

vapour catcher (A)

.

Fig. 10


Light ON

Speed 1
Light ON

Speed 2
Light ON

Speed 3
Light ON

OFF

Speed 1
Light OFF

Speed 2
Light OFF

Speed 3
Light OFF

Maintenance

ATTENTION!

Before performing any maintenance operation,

isolate the hood from the electrical supply by switching off at
the connector and removing the connector fuse.
Or if the appliance has been connected through a plug and
socket, then the plug must be removed from the socket.

Cleaning

The cooker hood should be cleaned regularly (at least with the
same frequency with which you carry out maintenance of the
fat filters) internally and externally.  Clean using the cloth
dampened with neutral liquid detergent. Do not use abrasive
products.

DO NOT USE ALCOHOL!

WARNING:

Failure to carry out the basic cleaning

recommendations of the cooker hood and replacement of the
filters may cause fire risks.
Therefore, we recommend observing these instructions.
The manufacturer declines all responsibility for any damage to
the motor or any fire damage linked to inappropriate
maintenance or failure to observe the above safety
recommendations.

Panel

Fig. 8

Dismantling:

pull the panel out decisively and remove it from all the
connecting points.

Cleaning:

the panel should be cleaned with the same frequency as
the fat filters, using a cloth soaked in neutral liquid
detergents.
Avoid the use of products containing abrasives. DO NOT
USE ALCOHOL!

Montage:

The panel should be fixed between the pins placed for
this reason on the surface of the hood.

Attention!

Always check that the panel is fixed in its

place well.

Grease filter

Fig. 1-7
Traps cooking grease particles.

The grease filter

 must be cleaned once a month using non

aggressive detergents, either by hand or in the dishwasher,
which must be set to a low temperature and a short cycle.
When washed in a dishwasher, the grease filter may discolour
slightly, but this does not affect its filtering capacity.
To remove the grease filter, pull the spring release handle.

Charcoal filter (filter version only)

Fig. 6
It absorbs unpleasant odours caused by cooking.

The saturation of the

charcoal filter

 occurs after more or less

prolonged use, depending on the type of cooking and the
regularity of cleaning of the grease filter.
In any case it is necessary to replace the cartridge at least
every four mounths.
The charcoal filter may NOT be washed or regenerated.
