8

 WARNING!

•  Failure to install the screws or fixing device in accordance

with these instructions may result in electrical hazards.

•  Do not use with a programmer, timer, separate remote

control system or any other device that switches on

automatically.

• This appliance is marked according to the European directive

2012/19/EC on Waste Electrical and Electronic Equipment

(WEEE).

• By ensuring this product is disposed of correctly, you will help

prevent potential negative consequences for the environment and

human health, which could otherwise be caused by inappropriate

waste handling of this product.

• The symbol

 on the product, or on the documents

accompanying the product, indicates that this appliance may not

be treated as household waste. Instead it should be taken to the

appropriate collection point for the recycling of electrical and

electronic equipment. Disposal must be carried out in accordance

with local environmental regulations for waste disposal.

• For further detailed information regarding the process, collection

and recycling of this product, please contact the appropriate

department of your local authorities or the local department for

household waste or the shop where you purchased this product.

Appliance designed, tested and manufactured according to:

• Safety: EN/IEC 60335-1; EN/IEC 60335-2-31, EN/IEC 62233.

• Performance: EN/IEC 61591; ISO 5167-1; ISO 5167-3; ISO

5168; EN/IEC 60704-1; EN/IEC 60704-2-13; EN/IEC 60704-3; ISO

3741; EN 50564; IEC 62301.

• EMC: EN 55014-1; CISPR 14-1; EN 55014-2; CISPR 14-2;

EN/IEC 61000-3-2; EN/IEC 61000-3-3. Suggestions for a correct

use in order to reduce the environmental impact:  Switch ON the

hood at minimum speed when you start cooking and kept it

running for few minutes after cooking is finished. Increase the

speed only in case of large amount of smoke and vapor and use

boost speed(s) only in extreme situations. Replace the charcoal

filter(s) when necessary to maintain a good odor reduction

efficiency. Clean the grease filter(s) when necessary to maintain a

good grease filter efficiency. Use the maximum diameter of the

ducting system indicated in this manual to optimize efficiency and

minimize noise.

If the product exterior is made using a special material, which

is non-standard for the type of hood application, such as

Wood, Porcelain stone and Krion, any distinctive marks,

differences in colour and surface deformations shall not be

considered as defects but rather a characteristic of the

material itself.

In the specific case of wood, this is a noble, natural and living

material that tends to change over time. This makes each

product unique and unrepeatable.

Use

The hood is designed to be used either for exhausting or filter

version.

 Extraction version

In this case the fumes are conveyed outside of the building by

means of a special pipe connected with the connection ring

located on top of the hood.

 CAUTION!

The exhausting pipe is not supplied and must be purchased

apart.

Diameter of the exhausting pipe must be equal to that of the

connection ring.

 CAUTION!

If the hood is supplied with active charcoal filter, then it must

be removed.

Connect the hood and discharge holes on the walls with a

diameter equivalent to the air outlet (connection flange).

Using the tubes and discharge holes on walls with smaller

dimensions will cause a diminution of the suction performance

and a drastic increase in noise.

Any responsibility in the matter is therefore declined.

!  Use a duct of the minimum indispensable length.

!  Use a duct with as few elbows as possible (maximum

elbow angle: 90°).

!  Avoid drastic changes in the duct cross-section.

 Filtration version

The aspirated air will be degreased and deodorised before

being fed back into the room.

In order to use the hood in this version, you have to install a

system of additional filtering based on activated charcoal.
