42

65cm from gas or mixed cookers.
If the instructions for installation for the gas hob specify a
greater distance, this must be adhered to.

  Electrical connection

The mains power supply must correspond to the rating
indicated on the plate situated inside the hood. If provided with
a plug connect the hood to a socket in compliance with current
regulations and positioned in an accessible area. If it not fitted
with a plug (direct mains connection) or if the plug is not
located in an accessible area apply a bi-polar switch in
accordance with standards which assures the complete
disconnection of the mains under conditions relating to over-
current category III, in accordance with installation
instructions.

Warning:

Before re-connecting the hood circuit to the mains

supply and checking the efficient function, always check that
the mains cable is correctly assembled.

Mounting

Fig. 5-6-7

Before beginning installation:

•

Check that the product purchased is of a suitable size for
the chosen installation area.

•

To facilitate installation, remove the fat filters and the
other parts allowed and described here, dismantle and
mount it.

To remove see also the relative paragraphs.

•

Remove the active carbon (*) filter/s if supplied (see also
relative paragraph). This/these is/are to be mounted only
if you want lo use the hood in the filtering version.

•

Check (for transport reasons) that there is no other
supplied material inside the hood (e.g. packets with
screws (*), guarantees (*), etc.), eventually removing
them and keeping them.

•

If possible, disconnect and move freestanding or slide-in
range from cabinet opening to provide easier access to
rear wall/ceiling. Otherwise put a thick, protective
covering over countertop, cooktop or range to protect
from damage and debris. Select a flat surface for
assembling the unit. Cover that surface with a protective
covering and place all canopy hood parts and hardware
in it.

•

Disconnect the hood during electrical connection, by
turning the home mains switch off.

•

In addition check whether near the installation area of the
hood (in the area accessible also with the hood mounted)
an electric socket is available and it is possible to
connect a fumes discharge device to the outside (only
suction version).

•  Carry out all the masonry work necessary (e.g.

installation of an electric socket and/or a hole for the
passage of the discharge tube).

Expansion wall plugs are provided to secure the hood to most
types of walls/ceilings. However, a qualified technician must
verify suitability of the materials in accordance with the type of
wall/ceiling. The wall/ceiling must be strong enough to take
the weight of the hood.

Do not tile, grout or silicone this

appliance to the wall. Surface mounting only.

Attention! The chimney is predisposed for installation of
the filter Version.

In certain models where it is required to use the cooker hood
in the suction version then it is possible to overturn the upper
section of the chimney
and insert it inside the lower section of the chimney so that the
air-exit perforations are not visible.
The chimneys in which this operation is possible are
recognizable by their bracket fixing points

G

which are

repeated also in the lower side of the upper section of the
chimney.

1.

   Using a pencil, draw a line on the wall, extending up to

the ceiling, to mark the centre.  This will facilitate
installation.

2.

   Rest the drilling template against the wall: the vertical

centre line printed on the drilling template must
correspond to the centre line drawn on the wall, and the
bottom edge of the drilling template must correspond to
the bottom edge of the hood.

3.

   Rest the support bracket on the drilling template so that it

coincides with the dotted rectangle, mark the two outer
holes and drill them (mark and also carry out upper drill
holes - 3a),  remove the drilling template, insert 4 wall
plugs and fix the hood support bracket into place using
two 5x45mm screws.

4.

   Hang the hood on the bracket.

5.

   Adjust the distance of the hood from the wall.

6.

   Adjust the horizontal position of the hood.

7.

Remove the carbon filter frame (see also Fig. 3); mark
the drill hole, using a pencil, for fastening the hood to the
wall.

8.

   Remove the hood from the bracket.

9.

   Drill at the point marked (Ø8mm - see operation 7).

 Insert 1 wall plug.

10.

  Rest the chimney support bracket „G“ against the wall,

touching the ceiling.  Use the support bracket as a drilling
template (the small slot formed on the support must
coincide with the line drawn on the wall as above –
operation 1) and mark 2 holes with a pencil, dril the holes
(Ø8mm), insert 2 wall plugs.    Fix  the  chimney  support
bracket to the wall using two 5x45mm screws.

11.

  Fix the bracket Z with two screws, so that the bracket

blocks the lower section of the telescopic chimney
(external covering) to the wall.

12.

   Connect a pipe (pipe and pipe clamps not provided, to be

purchased separately) for discharge of fumes to the
connection ring located over the suction motor unit.

13.

Insert the flue.

14.

   Hook the hood onto the bottom bracket.

15.

  Fasten the hood to the wall with 1   5x45 mm screw

(ABSOLUTELY NECESSARY), remount the carbon filter
frame (see also Fig. 3).

16.

Connect the tube to a fume expulsion device toward the
exterior in the case you want to use the hood in a filtering
version, then fix deflector

F

 to the support flues bracket

G

and connect  the end of the tube to the connection ring
on deflector

F

.

17.

   Make the electrical connections.
