DECORATIVE EXTRACTOR HOOD

Dear Customer,
Thank  you  for  buying  our  hood.  Please  read  these  instructions  carefully  for  its
optimum installation, use and maintenance.

Notes: The figures mentioned in this manual are in the first pages.

Hood installation on walls (look for the  symbol in

the figures)

Warning:  consult  local  regulations  regarding  fumes  outlets.  Do  not
connect  the  hood  to  a  fume,  ventilation  or  hot  air  duct.  Confirm  that
room  ventilation  is  appropriate  with  the  local  authorities.  Make  sure

the  maximum  air  extraction  flow  rate  for  the  appliances  in  the  room  does
not  exceed  4  Pa  (0.04  mbar).The  room  must  have  adequate  ventilation  if  an
extractor hood is used simultaneously with appliances that run on gas or other
fuels.  The  evacuated  air  must  be  extracted  through  ducts  that  are  used  for
evacuating fumes from appliances that run on gas or other fuels. Regulations
regarding air extraction must be complied with.

Use a rigid PVC pipe with a min. Ø l20 mm to evacuate fumes outside.
The  above  restrictions  do  not  apply  to  hoods  with  no  fumes  outlet  to  outside
(recirculation system with activated charcoal filter).
Install  the  hood  in  line  with  the  instructions  on  the  template

Install  the

hood  in  line  with  the  instructions  on  the  template

provided.

For  gas  cooking  appliances  only:  the  minimum  distance  to  the  hood  must  be
at least 65 cm.
Connecting the hood to the grid

Warning:  before  connecting  the  hood:  switch  off  the  electricity  supply
and check that the supplied voltage and frequency coincide with that
indicated on the appliance nameplate.

If  the  extractor  hood  has  a  plug,  connect  it  to  a  power  socket  in  line  with
applicable regulations, located in an accessible area.
If  the  hood  does  not  have  a  plug,  connect  it  directly  to  the  electrical  grid,
protected by a separator device accessible for disconnection, in line with local
regulations.
Use of the hood – Safety

Warning: the hood may stop working during an electrostatic discharge
(e. g. lightning). This involves no risk of damage. Switch off the electricity
supply to the hood and reconnect after one minute.

Do not allow the hood to be used by children or persons with reduced (physical,
sensory  or  mental)  capabilities  or  lack  of  experience  and  knowledge,  unless
they have been given instruction concerning use of the appliance by a person
responsible for their safety.
Children should be supervised so that they do not play with the appliance.
To  avoid  the  risk  of  fire,  clean  the  metal  filter  regularly,  permanently  control
pans containing hot oil and do not flambé food underneath the hood.
Do  not  use  the  hood  if  it  shows  signs  of  damage  or  imperfection.  Contact  an
official distributor or authorised dealer.
Accessible parts may heat up when using cooking appliances.

Use of the hood - Control panel (look for the

symbol in the figures)

The  different  control  panels  are  described  below.  Check  the  panel  model
installed on your hood and see the figure indicated in each case.
Panel with sliding switch (Fig. P1)

Extractor fan speed - positions: OFF, speed 1, 2 and 3

1-

Extractor fan operating control pilot light.

2-

Lighting on and off switch.

3-
Panel with electronic button (Fig. P2)

Lighting on and off.

1-

Lighting operating control pilot light.

2-

Extractor fan speed - button: speed 1, 2 and 3 Press the current speed again

3-

to switch off the extractor fan.
Extractor fan operating speed control pilot light.

4-

Timer: keep the chosen speed button pressed down for two seconds until the
display  flashes.  The  extractor  fan  stops  after  15  min.  and  the  lighting  switches
off. To cancel the timer: press the chosen speed button once.

Four-speed panel - Digital display (Fig. P3)

Lighting on and off.

1-

Extractor fan on and off.

2-

Decrease extractor fan speed.

3-

Extractor fan speed display panel.

4-

Increase extractor fan speed.

5-

Enable extractor fan turbo speed.

6-

Enable and disable extractor fan timer.

7-

Timer: the extractor fan works for 5 min. at the current speed and another 5 min.
at each of the lower speeds until it stops and the lighting switches off.

Five-button panel (Fig. P4)

Extractor fan operating control pilot light.

1-

Lighting on and off.

2-

Extractor fan off.

3-

Extractor fan speed - button: speed 1, 2 and 3

4-
Touch panel (Fig. P5)

Filter  clean  warning  display/button.

1-

Warning  of  the  need  to  replace  the

filter – press to deactivate once the filter has been cleaned or replaced.

Enable and disable extractor fan timer.

2-

Lighting on and off.

3-

Keep pressed down to adjust the lighting intensity.

Extractor fan on and off.

4-

Extractor fan speed - button: speed 1, 2 and 3/4

5-

Timer:  the  extractor  fan  works  for  5  min.  at  the  current  speed  and  another  5
min. at each of the lower speeds until it stops.

Sliding touch panel (Fig. P6)
1-   Extractor fan on and off.
2-   Sliding touch panel for extractor fan speed control. Also used in combination

with button

-3-.

3-   Lighting  on  and  off.

  Press  the  button  and,  while  it  is  flashing,  adjust  the

lighting intensity using the sliding touch panel -2-.

4-   Enable and disable extractor fan timer.
5-   Filter  clean  warning  display/button.

Warning  of  the  need  to  replace  the

filter – press to deactivate once the filter has been cleaned or replaced.

Timer: the extractor fan works for 2 min. at the current speed and another 2 min.
at each of the lower speeds until it stops and the lighting switches off.

Warning on the ZEN Model
The front panel automatically extends and retracts on switching the hood on/
off.
Hood maintenance

Warning:  always  switch  off  the  electricity  supply  before  carrying  out
maintenance  work  on  the  hood.

In  the  event  of  a  fault,  contact  an

official distributor

or authorised dealer.

Exterior  cleaning:  use  non-corrosive,  liquid  detergent  and  avoid  the  use  of
abrasive cleaning products.
Grease  filters:  to  avoid  fires,  clean  thoroughly  once  a  month  or  whenever  the
display pilot light indicates as such. To do so, remove the filters and wash with
hot  water  and  detergent.  If  using  a  dishwasher,  position  the  filters  vertically  to
prevent solid remains from depositing on them.
Activated charcoal filters: replace the every 3 months.

Important: increase the filter cleaning/replacement frequency if the hood
is  used  for  more  than  2  hours  a  day.  Always  use  genuine  filters  from  the
manufacturer.

Bulb replacement (look for the

symbol in the figures)

Warning:  do  not  handle  the  bulbs  until  the  electricity  supply  has  been
switched off and they have cooled.

Important:  use  new  bulbs  according  to  that  indicated  on  the  hood
nameplate.

Use  bulbs  with  an  aluminium  reflector  to  replace  halogen  bulbs.  Do  not  use
dichroic bulbs - risk of overheating.

Legal information
The manufacturer:
- Declares that this product meets all basic requirements regarding low-voltage
electrical equipment established in Directive 2006/95/EC of 12 December 2006
and electro-magnetic compatibility established in Directive 2004/108/EC of 15
December 2004.
- Is not responsible for any failure to observe the instructions given in this manual
and current safety regulations for the correct use of the equipment.
- R eserves the right to make any modifications to the equipment or this manual
without prior notice.

Contact  our  official  distributor  should  you  require  technical  assistance  or
additional information on our products.

EN
