In this version, the air passes through charcoal filters for purification, and is then recirculated back

into the kitchen.

Check that the charcoal filters are fitted to the motor, and if not, install them as described in the

previuous image.

If the hood is of filtering type, remove the non-return valve fitted at the motor’s outlet.

For maximum efficiency, the third speed should be used when there are strong odours or a lot of

steam, the second speed in normal conditions, and the first speed for keeping the air clean with

minimum energy consumption. The range hood should be switched on when starting to cook, and

left on until the odours disappear.

ELECTRONIC CONTROL PANEL (Fig. 7)

Light pushbutton (1)

- ON: light on (the pushbutton is lit);

- OFF: light off;

Pushbutton - (3)

Press to reduce motor speed.

Pushbutton + (3)

Press to increase motor speed.

(In the speed 4 the pushbutton presents an intermittant light. The speed 4 or intensive is timed and

after 7 minutes the motor automatically switches to speed 3).

Pushbutton On / Off (2)

Function: it turns hood on and off.

When you switch On the hood the motor starts at first speed.

Pushbutton Timer (4)

This function allows the automatic turning off the hood after 15 minutes for the speeds 1, 2, 3 (the

pushbutton is lit).

METAL FILTERS

Open the panel (Fig. 4). Use handle to remove the metal grease filter.

CHARCOAL FILTERS

To replace the charcoal filters, proceed as follows: remove the metal filters as described above.

The two filters located at the ends of the motor can now be easily accessed.

To install the new fi lters see picture.

The hood is equipped with high efficiency, low power consumption LED lighting (light on the work

top and decorative light on the glass panes), with high durability under normal use conditions.

On the product there are two leds from 1,1 watts.

OPERATIONS

FILTER REMOVING

LIGHTING

INSTALLATION IN RECIRCULATING MODE
