carry out instructions for mounting filter version cooker hood.

•  FILTERING VERSION

IInstall the cooker hood and the two connectors as described in the
paragraph mounting the exhausting  version cooker hood.
To mount the filter connector refer to instructions included in the kit.
If the kit is not supplied, then order the kit as an accessory from your
local dealer. The filters must be fitted to the fan unit placed inside the
cooker hood. The air is replaced in the environment via the eyelets
impressed on the connector E.

USE AND MAINTENANCE

•

It is recommended to operate the appliance prior to cooking.

It is recommended to leave the appliance in operation for 15 minutes
after cooking is terminated in order to completely eliminate cooking
vapours and odours.
The proper function of the cooker hood is conditioned by the regularity
of the maintenance operations, in particular, the active carbon filter.

•

The anti-grease filters capture the grease particles suspended in the

air, and are therefore subject to clogging according to the frequency of
the use of the appliance.
In order to prevent fire hazard, it is recommendable to clean the filter
at a maximum of 2 months by carrying out the following instructions:
- Remove the filters from the cooker hood and wash them in a solution
of water and neutral liquid detergent, leaving to soak.
- Rinse thoroughly with warm water and leave to dry.
- The filters may also be washed in the dishwasher.
The aluminium panels may alter in colour after several washes. This
is not cause for customer complaint nor replacement of panels.

•

The active carbon filters purify the air that is replaced in the

environment.  The filters are not washable nor re-useable and must be
replaced at maximum every four months. The saturation of the active
carbon filter depends on the frequency of use of the appliance, by the
type of cooking and the regularity of cleaning the anti-grease filters.

•

 Clean the fan and other surfaces of the cooker hood regularly using

a cloth moistened with denatured alcohol or non abrasive liquid
detergent.

CONTROLS: 1A)ELECTRONIC 1B)LOGIC

_(FIG.5)

A

 = LIGHT

B

 = OFF/SPEED I

C

 = SPEED II

D

 = SPEED III

E

 = AUTOMATIC STOP TIMER – 15 minutes

F

 = FILTER SATURATION RESET LIGHT

L

 = LOGIC

When the “filter saturation” light flashes, the anti-grease filters must
be washed.
When the light comes on without flashing, the anti-grease filters must
be washed and the carbon filters replaced (in case of operation whit the
recycling version).
When this operation has been completed, press the key to reset it.
The “automatic stop timer” delays stopping of the hood, which will
continue functioning for 15 minutes at the operating speed set at the
time this function is activated.

• LOGIC

a.

AUTOMATIC LIGHT PLUS MOTOR OPERATION

Ensure that the cooker hood is in the

OFF

position and depress the

logic button.  The motor starts up at the speed selection 1 and the lights
remain switched off.  When the Logic function detects the presence of
a person or an increase in fumes and/or vapour, the lights turn on
automatically and the motor moves to speed

selection 2

. After

15

seconds

the light switches off and the motor returns to the speed

selection 1

. Depress the Logic button to disactivate the Logic function.

b.

AUTOMATIC LIGHT OPERATION

Ensure that the the cooker hood is in the

OFF

position, depress the light

button and then the Logic button.
The lights switch on automatically when the Logic function detects the
presence of a person.
The light switches off after 15 seconds.

Depress the Logic button to disactivate the Logic function.

c.

AUTOMATIC MOTOR OPERATION

Ensure that the the cooker hood is in the

OFF

 position, depress the

motor start button on speed selection

1

or

2

 and then the Logic button.

When the Logic function detects the presence of

a person or the increase of fumes and/or vapour

it will increase the motor speed automatically.

Depress the Logic button in order to disactivate the Logic function.

THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR

EVENTUAL DAMAGES CAUSED BY BREACHING THE ABOVE

WARNINGS.

ENGLISH

GENERAL

Carefully read the following important information regarding installation
safety and maintenance. Keep this information booklet accessible for
further consultations.  The appliance has been designed as a exhausting
version (external exhaust) or as a filter version (internal air recycle)
cooker hood.

SAFETY PRECAUTION

1.

Take care when the cooker hood is operating simultaneously with an

open fireplace or burner that depend on the air in the environment and
are supplied by other than electrical energy, as the cooker hood removes
the air from the environment which a burner or fireplace need for
combustion.
The negative pressure in the environment must not exceed 4Pa (4x10
-5 bar).
Provide adequate ventilation in the environment for a safe operation of
the cooker hood.
Follow the local laws applicable for external air evacuation.

2. WARNING  !

In certain circumstances electrical appliances may be a danger

hazard.

A ) Do not check the status of the filters while the cooker hood

is operating

B ) Do not touch the light bulbs after appliance use

C ) Flambè cooking is prohibited underneath the cooker hood

D ) Avoid free flame, as it is damaging for the filters and a fire

hazard

E) Constantly check food frying to avoid that the overheated

oil may become a fire hazard

F ) Disconnect the electrical plug prior to any maintenance.

G)    This appliance is not intended for use by young children or

infirm persons without supervision

H)   Young children should be supervised to ensure they do not

play with the appliance

I)    There shall be adequate ventilation of the room when the

rangehood is used at the same time as appliances burning gas

or other fuels

L)       There is a risk of fire if cleaning is not carried out in accordance

with the instructions

INSTALLATION INSTRUCTIONS

• ELECTRIC CONNECTION

The appliance has been manufactured as a class II, therefore no earth
cable is necessary.
The connection to the mains is carried out as follows:
BROWN =

L

 line

BLUE =

N

 neutral

If not provided, connect a plug for the electrical load indicated on the
description label. Where a plug is provided, the cooker hood must be
installed in order that the plug is easily accessible.
An omnipolar switch with a minimum aperture of 3mm between
contacts, in line with the electrical load and local standards, must be
placed between the appliance and the network in the case of direct
connection to the electrical network.
• The appliance must be installed at a minimum height of 650 mm from
an cooker stove in case of a gashob or an electrical hob.
If a connection tube composed of two parts is used, the upper part must
be placed outside the lower part.
Do not connect the cooker hood exhaust to the same conductor used
to circulate hot air or for evacuating fumes from other appliances
generated by other than an electrical source.
• Exhaust must not be discharged into a flue which is used for exhausting
fumes from an appliance burning gas or other fuels

• MOUNTING THE COOKER HOOD TO THE WALL

Drill holes

A-C-D

 according to indications quoted in (fig. 3).

Use screws and screw anchors suitable for wall (e.g. reinforced
cement, plasterboard) for the mounting of the cooker hood.
Where screws and screw anchors are supplied ensure that they are
suitable for the type of wall where the cooker hood is to be mounted.
Lock in the flange connector

Y

 to the cooker hood (fig. 2).

Affix the bracket

Z

 to the wall via the drill holes

A

Hang the cooker hood on the wall using the drill holes

C

.

Fasten the cooker hood using the fastening drill holes

D

.

• EXHAUSTING VERSION

Connect the flange

Y

 to the discharge opening with a connecting tube

(do not carry out for filter version).
Insert the upper exhausting of the chimney

E

 inside the lower section

F

. Fix the lower of the chimney tothe hood by the screws

H

 supplied

(fig. 2). Pull out the upper section up to bracket

Z

 and fix the screws

L

(fig. 2)In order to transform your cooker hood from suction version to
filter version, ask your local retailer for active carbon filters and then
