USE

A

B

C

D

E

F

Button Function

Specifications

A

Hood  Functions  On/Off

When  the  button  is  touched  with  the  hood  turned  off,  all  functions  light  up

(intensity  50%)  and  are  enabled.

When  the  button  is  touched  with  the  hood  in  operation,  all  functions  are  turned

off  and  disabled  (Motor  Off  +  Lights  Off).

B

Manages  motor  speed:0--

V1--V2--V3--V4--P

When  the  area  is  touched,  the  motor  starts  at  the  speed  required.

P  =  Intensive  Speed,  timed  for  5  minutes,  after  which  the  system  returns  to  the

previous  speed.  When  activated  from  Motor  Off  it  returns  to  speed  V1.When

the  required  speed  is  touched,  it  will  become  brighter  (intensity  100%)  than  the

other  functions  (intensity  50%).

C

Delay  function

Touching  this  button  activates  automatic  shutdown  of  the  Motor,  the  Fans  and

the  Lighting  with  a  10  minute  delay.  It  can  only  be  activated  with  the  motor  on,

running  at  any  speed  except  Intensive,  and  with  the  Sensor  =  Off.

Enables  /  Disables  the

Remote  Control  Receiver.

When  this  button  is  pressed  and  held  for  4  seconds  (Motor  Off  +  Lights  Off,  in

the  absence  of  other  alarms,  the  Led  will  light  up  for:

4  seconds  to  indicate  that  the  Remote  Control  has  been  Activated

2  seconds  to  indicate  that  the  Remote  Control  has  been  Deactivated

D

Sensor

In  this  mode  the  Hood  operates  automatically  for  a  maximum  of  5  hours,  after

which  it  switches  the  Motor  off.  The  hood  modifies  the  speed  of  the  motor

according  to  the  findings  of  the  sensor.

Buttons  B  and  C  do  not  work.  The  function  is  disabled  by  pressing  the  Button  or

turning  the  hood  off.

E

Manages  Lighting

Intensity:0--L1--L2--L3-

-LMax

When  this  area  is  touched,  the  Lights  turn  on  at  the  required  intensity.

When  the  lighting  intensity  is  touched,  it  will  become  brighter  (intensity  100%)

than  the  other  functions  (intensity  50%).

F

Filter  ResetResets  the

Filter  Saturation  alarm

when  the  button  is  tou-

ched  with  the  motor  and

lighting    turned  off.

After  100  hours  operation  the  Led  lights  up  continuously  to  indicate  saturation

of  the  Metal  Grease  Filters.After  200  hours  operation  the  Led  flashes  to  indicate

saturation  of  the  Activated  Charcoal  Filters.

Enables/Disables  the

Activated  Charcoal  Filter

Alarm.

When  this  button  is  pressed  and  held  for  4  seconds(Motor  Off  +  Lights  Off),  in

the  absence  of  other  alarms,  the  Led  will  light  up  for:

4  seconds  to  indicate  that  the  Activated  Charcoal  Filter  Alarm  has  been  activated

2  seconds  to  indicate  that  the  Activated  Charcoal  Filter  Alarm  has  been  deacti-

vated

After connecting the hood to the mains, the commands are activated after 4seconds. When the Hood is switched off, none of the fun-
ctions is displayed, and only the normal lettering on the control panel is visible. All the rest will light up (intensity 50%) when button A
is touched. The controls are activated by touching the selected function, which will light up more brightly (intensity 100%) with respect
to the other hood functions (intensity 50%). When no commands are given for at least 10 seconds, only the selected functions will be
lighted (Intensity 100%) and all the rest will turn off (Intensity 50%). After 7 hours in operation, if no further commands are given the
hood will switch off (Motor Off + Lights Off), from here you can touch for activated the function, and the next touch you can select the
desired function.It is possible to activate one of the hood functions (Speed and Lighting) not just by touching the control panel, but also
by placing a finger on the panel and sliding it towards the chosen function without lifting it off. If the motor and lights are turned off, by
setting them to zero, all the command LEDs will remain on at 50%, and if no further commands are given in the next 10 seconds, then all
the LEDs will be turned off with the exception of the “0” LEDs, which will remain on for a further 15 minutes.
