www.timberk.com • electrical storage water heater

9

Termostat handale

SWH ME2 series

1. At first, open one of the discharge valves on the outlet of the water

heater, then open the inlet valve. The electric water heater will start filling

with water. When water flows from the outlet valve freely, it means the water

heater is fully filled with water and you can close the discharge tap.
Warning: During normal operation the inlet valve must be set “open”.
2. Plug the power cord into the outlet, an indicator light will light up.

3. The appliance can automatically control water temperature. When

water temperature in the water heater reaches the temperature, set by the

user, the heating is automatically switched off, and water temperature will

be maintained due to the heat insulation layer; when water temperature

drops to a certain level, heating is automatically switched off, in such a

way continuous hot water supply is provided. When the water heater

automatically switches off, the indicator light goes out.

9. WATER HEATER OPERATION

IMPORTANT!

Power outlet must be designed for rated current not

less than 10A, copper stranded power cord not less

than 3 x 1.5 mm

2

 in cross section (for copper).

4. If you will turn the thermostat handle clockwise, you’ll increase the

temperature of heating. Maximum temperature inside inner tank is +75°C

approx. If you want to reduce the temperature of water, please, turn the

handle anticlockwise.
5. If you choose position of thermostat handle like “optimum” or            , it

means you choose the most comfortable water temperature +58°C (±2°C).
6. The appliance can automatically control water temperature. When

water temperature in the water heater reaches the temperature, set by the

user, the heating is automatically switched off, and water temperature will

be maintained due to the heat insulation layer; when water temperature

drops to a certain level, heating is automatically switched off, in such a

way continuous hot water supply is provided. When the water heater

automatically switches off, the indicator light goes out.
7. If you will turn the thermostat handle clockwise, you’ll increase the

temperature of heating. Maximum temperature inside inner tank is +75°C

approx. If you want to reduce the temperature of water, please, turn the

handle anticlockwise.
8. If you choose position of thermostat handle like “optimum” or           , it

means you choose the most comfortable water temperature +58°C (±2°C).

10. MAINTENANCE

Fig. 8

Fig. 9

Fig. 7
