Instructions for use and maintenance

       7

EN

English

IV.

DESCRIPTION AND PRINCIPLE OF WORK

The appliance consists of a body, flange at the bottom side /for water

heaters intended for vertical mounting/ or at the sides /for water

heaters intended for horizontal mounting/, protective plastic panel

safety-return valve.

1.

The body consists of a steel reservoir (water tank) and housing

(outer shell) with thermal insulation placed in-between made of

ecologically clean high density polyurethane foam, and two pipes with

thread G ½ ‘’ for cold water supply (marked by a blue ring) and hot

water outlet pipe (marked by a red ring).

The inner tank may be of two types depending on the model:

 •

Made of steel protected form corrosion by a special glass-ceramics

coating

 •

Made of stainless steel

The vertical water heaters may be outfitted with a built in heat

exchange unit (serpentine tube). The heat exchenger’s entrance and

exit are located at the sides and represent pipes with thread G ¾ ‘’.

2.

  The flange is outfitted with: electric heater and thermostat.

The water heaters with glass-ceramics coating are outfitted with a

magnesium protector.

The electric heater is used for heating the water in the tank and is

managed by the thermostat, which automatically maintains the set

temperature.

The thermostat has a built in overheating safety device, which switches

of power to the heater when the water temperature reaches excessive

values.

3.

  The safety-return valve prevents the appliance’s complete

emptying in the event the cold water supply is interrupted. The

valve protects the appliance from pressure increases higher than the

allowed value during heating (! pressure increases upon an increase

of temperature), via release of excess pressure during the drainage

opening.

The safety-return valve cannot protect the appliance in the

event of water mains pressure in excess of the acceptable

pressure stated for the appliance.

V.

MOUNTING AND SWITCHING ON

Attention! Improper installation and connection of the

appliance may make it hazardous for the health and life

of consumers. It may cause grievous and permanent

consequences, including but not limited to physical injuries and/

or death. Improper installation and connection of the appliance

may also lead to damage to the consumers’ property /damage

and/ or destruction/, or to that of third persons, as a result of, but

not limited to flooding, explosion and/or fire.

Installation, connection to the main water and power supply, and

putting into operation must be carried out by certified electricians

and technical personnel certified in installation of this category of

appliances, who have obtained their license in the state where the

installation and commissioning of the appliance are carried out, and in

compliance with its local legislation.

Notice

: The installation of the unit is at the buyer’s expense.

 •

The valve and the elements linked to it must be protected from freezing.

 •

During the heating the appliance could produce a hissing noise (the boiling water).

This is common and does not indicate any damage. The noise gets higher with the

time and the reason for this is the accumulation of limestone. To remove the noise

the appliance must be cleaned from limestone. This type of cleaning is not covered

by the warranty.

 •

In order to secure the water heater’s safe operation, the safety return-valve must

undergo regular cleaning and inspections for normal functioning /the valve must

not be obstructed/, and for the regions with highly calcareous water it must be

cleaned from the accumulated lime scale. This service is not provided under warranty

maintenance.

All alterations and modifications to the water heater’s construction and electrical

circuitry are forbidden. If such alterations or modifications are established during

inspection, the appliance’s warranty shall be null and void. Alterations and

modifications shall mean each instances of removal of elements incorporated by the

manufacturer, building in of additional components into the water heater, replacement

of elements by similar elements unapproved by the manufacturer.

 •

These instructions shall also apply to water heaters equipped with a heat

exchanger.

 •

If the power supply cord (of models that have one) is damaged, it must be replaced

by a service representative or a person with similar qualification, to avoid any risk.

 •

This appliance can be used by children aged from 8 years and above and persons

with reduced physical, sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction concerning use of the

appliance in a safe way and understand the hazards involved.

 •

Children shall not play with the appliance.

 •

Cleaning and user maintenance shall not be made by children without supervision.
