Installation instructions

TR1000 4 T, TR1000 5 T, TR1000 6 T, TR1000 6 B – 6 720 876 020 (2019/06)

20

3

Installation instructions

Install the continuous-flow heater as described in the
illustrated section. Observe the instructions in the text.

3.1

Installation

I.  Unpacking/scope of supply

•

Unpack the appliance and check for transport damage.

•

Dispose of the packaging and, where applicable, the old
appliance, in an environmentally conscious manner.

3.1.1 Preparation for installation

CAUTION:

Important!

Only use the enclosed installation set.

•

Shut off water supply. The electrical connection
(connection cable) must be disconnected from the power
supply. Unscrew the fuse or switch off the circuit breaker.

•

There must be a clearance of approximately 60mm on all
sides of the appliance for installation.

•

Observe the technical data for the appliance.

•

TR1000 5 T, TR1000 6 T, TR1000 6 B:

 Unscrew

the screws on the housing cover and remove the lid.

II. Wall mounting

•

Secure the appliance using the installation template,
screws and wall plugs so that it is vertical and flush against
the wall:

•

TR1000 5 T, TR1000 6 T, TR1000 6 B:

 For an exposed

electrical connection, the different methods of routing the
supply line found on the assembly template must be
observed.

•

TR1000 5 T, TR1000 6 T, TR1000 6 B:

 The sleeve must fit

tightly round the connection cable. If the sleeve is damaged
during installation, the holes must be sealed water-tight.

III. Water connection

A

 Pressurised connection

•

For a pressurized connection, the tap and outlet fittings
must be approved for operation with closed (pressurized)
continuous-flow heater system.

B

  Depressurised connection

•

Fit the jet regulator supplied.

•

Check the inserted filter and sleeve in the water inlet.

•

Ensure that the connection pipes are fitted to the adapter
along the axis of the pipes.

•

Tighten the union nuts firmly to the adapter with an open-
jawed spanner.

The T-piece and flexible connecting hose (for pressurised
connection) are available from a specialist store.

For a depressurised connection, a depressurised fitting must
be used, e.g. fitting BZ13051 which can be obtained as
a special accessory.

IV. Electrical connection

C

 Flow switch

D

  Temperature limiter

•

TR1000 4 T:

 Connect the appliance to the mains.

TR1000 5 T, TR1000 6 T, TR1000 6 B

The installation of non plug-in ready appliances must be
undertaken by the respective utility operator or by a qualified
specialist company, who can also assist you when you are
requesting the approval of the utility company for installation
of the appliance.

The appliances must be connected with a NYM-J3x4 (mm

2

)

mains lead. Leads with a larger cross-section must not be used.

•

Connect the appliance in accordance with the connection
diagram on the strip terminal.

•

Screw the housing cover back on.

•

After installation, give the user the operating
instructions and explain how the appliance works.

TR1000 6 B

High level appliance

TR1000 4 T
TR1000 5 T
TR1000 6 T

Under counter appliances

1

Housing

2

Mounting (2 screws, 2 wall plugs)

3

ON indicator (only on the TR1000 6 B)

4

Filter and sleeve (inserted in inlet)

5

Jet regulator and seal

6

Only for appliances with a permanent electrical
connection: Rubber grommet

1

Locate the appliance on the screw and press down.

2

Screw in the second screw through the mounting
tab and tighten.
