8

EN

Close cover Steps

A

B

Power Knob
Power Led
Water Inlet
Pressure Relief Valve
Filter

Water Outlet

This product conforms to Directive WEEE 2012/19/EU.

The symbol of the crossed waste paper basket on the ap pliance indicates that at the end of its working
life the pro duct should be disposed of separately from normal domestic household rubbish, it must be
disposed of at a waste dispo sal center with dedicated facilities for electric and electronic appliances or

returned to the retailer when a new replace ment product is purchased. The user is responsible for the disposal of
the product at the end of its life at an appropriate waste disposal center. The waste disposal center (which using
special treatment and recycling processes effectively dismantles and disposes of the appliance) helps to protect
the environment by recy cling the material from which the product is made. For further information about waste
disposal systems visit your local waste disposal center or the retailer from which the product was purchased.

Power

kW Loaded

Heating Setting

Recomended Cable Size

Recomended

Fuse Rating

220V

230V

240V

AURES M 6

6

-

7.1

3.5+2.5 kW

H05VV-F 3x4 mm2

32 A

AURES M 7.7

7.7

-

9.1

4.4+3.3 kW

H05VV-F 3x6 mm2

40 A

AURES M 8

8

-

9.5

4.0+4.0 kW

H05VV-F 3x 6mm2

40 A

AURES M 10.5

10.5

-

12.5

5.25+5.25 kW

H05VV-F 3x10 mm

2

63 A

Power

kW Loaded

Heating Settin

Recomended Cable Size

Recomended

Fuse Rating

400V

415V

--

AURES M 12 TR

12

12.9

--

4+4+4 kW

H05VV-F 5G4

3 x 32 A

• Operating water pressure 50-800 kPa (0.5-8 bar) • Water pressure operating power switch

• Standard 1/2"Ø compression inlet connection  • Top-left cable entry • Bottom-right water entry

UNIT DIMENSIONS: HEIGHT 180mm WIDTH 304mm DEPTH 110mm
UNIT DIMENSIONS: HEIGHT 220mm WIDTH 304mm DEPTH 110mm

Table 1: Recommended cable
