NAVITEL CR700

 |  15

EN

Device functions

Video

Connect the device to an external power supply and it will start recording automatically (indicated by

the flashing blue light). Press the OK button to stop recording (the blue light will become steady). Press

OK again to record another video. Each video will be saved automatically.


In

Video Record

 mode, press the Mode button to enter

Capture

 mode, press the OK button to take a

photo (it will be saved automatically).

Playback

In

Video Record

 mode, press the Mode button twice to enter

Playback

 mode; press the Up and Down

buttons to select a file; press the OK button to play a file. During playback, press OK to pause/unpause;

press the Up and Down keys to fast forward/rewind.

Lock file

In

Video Record

 mode, press Down to protect the current recording. A key symbol will appear at the

bottom of the screen. In

Playback

 mode, select a file, press Menu and select Protect, then Lock Current

or Lock All. Protected files cannot be deleted or overwritten. Select Unlock Current/Unlock All to remove

  protection.

Record audio

Record video with or without sound.

Loop recording

This setting allows saving the recording in separate files every few minutes. For example, if set to 5

minutes, 1 hour of footage will be saved as 12 five minute fragments. If the memory card is full, all

unprotected files will be overwritten in the order they were created.

WDR

Wide Dynamic Range provides more dynamic range and detailed image. Disabled by default.

G-sensor

If the vehicle is hit by something, the DVR will automatically lock the current video;

LED lamp

Turn on when it’s dark to improve image brightness.
