Instruction Manual

Instruction Manual

8. AV output
9. USB port
10. DC 5V power input for car adaptor
11. LED incdicator

Not indicated:

 memory card slot (back

side), camera (front side)

Operations

Mounting

•  Connect the threading hole on the bottom

of the unit to the threading pin on the upper
part of the stand by rotating the fastening
washer counter-clockwise.

•  Press the suction cup to a surface in the

car, then push the pressure valve down. Make
sure the stand is fixed properly to the surface.

•  You can adjust the angle of the stand by

loosening the upper and lower washers and
bending the assembly knots.

•  To unmount the stand, lift the pressure

valve, then lift the plastic ear on the suction cap.

Power and charging

To charge the battery of this unit connect

its USB port to the PC with the suppled USB
cable; or connect it to a car lighter socket with
the suppled car adapter. The power icon

on the top right corner of the display indicates
the remaining battery power.

Get ready for record

•  Before you start recording, insert an SD

memory card into the memory card slot of this
unit until a click. Insert the card with correct side.

•  Press ON/OFF button to switch the unit

on. A

 icon will be shown in the left upper

corner of the display showing that the unit is
ready for recording.

•  The unit will turn off automatically if there

are no operations within several seconds.

  SD capacity supported: up to 32 Gb.

For correct and satisfactory operation, licensed
SD memory cards of famous brands should be

used with this unit. Avoid using memory cards
of unknown brands.

Recording

•  When the unit is turned on, press OK

button to start recording video. The unit will
save video files automatically after each 2, 5 or
10 minutes (see “Setup“ paragraph below for
more details). When the memory card is filled,
old files will be deleted and the new files will be
recorded instead. Press OK button to stop and
to continue recording. When the environmental
lighting is not bright enough, the unit will
automatically activate the IR lights in the front
panel of the unit.

•  Press DOWN or UP button to zoom in or

out.

•  You can record video while charging the

unit. Connect this unit to a car lighter socket to
start charging it. The unit will be turned on and
start video recording at the same time when
your car engine is started. It would save video
files automatically and be switched off in 5
minutes after the car is stopped.

•  Before removing memory card stop

recording. Press on the card until a click to
remove it.

•  Motion detector recording is available

after you switch on this item in the setting
menu (see “Setup“ paragraph below for more
details). The unit will go to recording mode if
there is image motion in front of the lens. If
there is no motion within 2 minutes, then the
unit will automatically go to standby mode. In
standby mode, if there is motion again, the unit
will go to recording mode.

Photo mode

•  Press MODE button to choose the photo

mode. The upper left corner of screen will
display the

 icon. Press DOWN or UP

button to zoom in or out. Press OK button to
take a photo.

•  You can set such parameters of photo as

self timer, photo quality, metering mode, flash
and exposure. Please see “Setup“ paragraph
below for more details.
