80

Input/output
connectors

Video output

Phono jack, 1 Vp-p, 75 ohms,
unbalanced

Audio output

Monaural, phone jack, 327 mV

RFU DC OUT

Special minijack, DC 5V

LANC control jack

Stereo mini-minijack (ø 2.5 mm)

MIC jack

Monaural minijack (ø 3.5 mm)

General

Power requirements

7.2 V (battery pack)
8.4 V (AC power adaptor)

Average power consumption
(when using the battery pack)

During camera recording
2.3 W

Operating temperature

0 °C to 40 °C (32 °F to 104 °F)

Storage temperature

–20 °C to +60 °C (–4 °F to +140 °F )

Dimensions (approx.)

102

×

 106

×

 212 mm

(4 1/8

×

 4 1/4

×

 8 3/8 in.) (w/h/d)

Mass (approx.)

740 g (1 lb 10 oz )
excluding the battery pack, lithium
battery, cassette and shoulder strap
880 g (1 lb 15 oz )
including the battery pack
NP-F330, lithium battery CR2025,
cassette P5-90 and shoulder strap

Supplied accessories

See page 5.

Video camera
recorder

System

Video recording system

2 rotary heads
Helical scanning FM system

Audio recording system

Rotary heads, FM system

Video signal

PAL colour, CCIR standards

Usable cassette

8 mm video format cassette
Standard 8

Recording/playback time (using
cassette P5-90)

SP mode: 1 hour and 30 minutes
LP mode: 3 hours

Fastforward/rewind time (using
cassette P5-90)

Approx. 5 min.

Viewfinder

Electric viewfinder (monochrome)

Image device

1/6 inch CCD (Charge Coupled
Device)
Approx. 320,000 pixels
(Effective: Approx. 290,000 pixels)

Lens

Combined power zoom lens
Filter diameter 37 mm (1 7/16 in.)
20

×

 (Optical), 200

×

(Digital)

Focal length

3.6 - 72 mm (5/32 - 2 7/8 in.)
When converted to a 35 mm still
camera
51.8 - 1036 mm (2 - 40 6/8 in.)

Colour temperature

Auto

Minimum illumination

1 lux (F 1.4)
0 lux (in the NightShot mode)*
* Objects unable to be seen due to

the dark can be shot with infrared
lighting.

Specifications

AC power adaptor

Power requirements

100 - 240 V AC, 50/60 Hz

Power consumption

23 W

Output voltage

DC OUT: 8.4 V, 1.5 A in operating
mode

Operating temperature

0 °C to 40 °C (32 °F to 104 °F)

Storage temperature

–20 °C to +60 °C (–4 °F to +140 °F)

Dimensions (approx.)

125

×

 39

×

 62 mm

(5

×

 1 9/16

×

 2 1/2 in.) (w/h/d)

excluding projecting parts

Mass (approx.)

280 g (9.8 oz)
excluding mains lead

Battery pack

Output voltage

DC 7.2 V

Capacity

5.0 Wh

Dimensions (approx.)

38

×

 21

×

 71 mm

(1 9/16

×

13/16

 ×

2 7/8 in.) (w/h/

d)

Mass (approx.)

95 g (3.4 oz)

Type

Lithium ion

Design and specifications are
subject to change without notice.
