is fitted on protection grille rear as shown in illustration on page 2-3.
Close the two grilles by fastening the 8 fixing clips (13) (or 7 in the case
of Charly little). Ensure that all fixing clips (13) are fastened.

F.  Secure the two grilles (7 and 11) with securing screw (14).

Setting up / operation

1.  Place Charly at the desired position on a flat surface. Connect the mains

cable (17) to a suitable plug socket.

2.  Switch on the Charly fan at the controller (15) and set the desired speed

(Positions 1-3, from gentle breeze to powerful circulation).

3.  Push the oscillating knob (16) down to switch on the oscillation and pull

the oscillating knob up to switch off the oscillation.

4.  The direction of airflow can be set in 4 positions. By carefully moving

the motor housing (4) up and down, the direction can be adjusted (click-
ing noise).

Cleaning

Prior to any maintenance, cleaning and after each use, switch off the appli-
ance and unplug the mains cable (17) from the socket.

Attention:

Never submerge the appliance in water (danger of short-circuit).

• For external cleaning, rub with a damp cloth and then dry thoroughly.

• To clean the fan blades, remove securing screw (14), undo all fixing clips

(13) and carefully lift off protection grille front (11). Now you can wipe the
fan blades (9) with a damp cloth and dry well afterwards. After cleaning,
replace protection grille front (11) on appliance (fit top positioning clip: 12),
fasten all fixing clips (13) and fasten securing screw (14) tightly.

Repairs

• Repairs to electrical appliances must only be carried out by a qualified

electrical technician. If improper repairs are carried out, the warranty
lapses and all liability is refused.

• Never operate the appliance if the adaptor or plug is damaged, after it has

malfunctioned, if it has been dropped or has been damaged in any other
way (cracks/breaks in the casing).

• Do not push any object into the appliance.

• If the appliance is beyond repair, make it unusable immediately by cutting

through the cable and hand it in at the collection point provided for the
purpose.

Disposal

The European directive 2012 / 19 / CE on Waste Electrical and Electronic
Equipment (WEEE), requires that old household electrical appliances must
not be disposed in the normal unsorted municipal waste stream. Old appli-
ances must be collected separately in order to optimize the recovery and
recycling of the materials they contain and reduce the impact on human
health and the environment. The crossed out “wheeled bin” symbol on the
product reminds you of your obligation, that when you dispose of
the appliance it must be separately collected. Consumers should
contact their local authority or retailer for information concerning
the correct disposal of their old appliance.

• Never insert objects into the grille of the fan. Do not cover the appliance

during operation.

• Always disconnect the power cord from the socket before removing the

protection grille.

• Only connect the cable to alternating current. Observe the voltage infor-

mation given on the appliance.

• Do not use damaged extension cords.

• Do not run the power cord over sharp edges and make sure that it does

not get trapped.

• Do not pull the plug from the socket with wet hands or by holding on to

the power cord.

• Do not use the appliance in immediate vicinity of a bath tub, a shower or a

swimming pool (observe a minimum distance of 3 m). Place the appliance
such that a person in the bath tub cannot touch the appliance.

• Do not place the appliance near a heat source. Do not subject the power

cord to direct heat (such as a heated hotplate, open flames, hot iron sole
plates or heaters for example). Protect power cords from oil.

• See to it that the appliance is properly positioned to ensure a high stabil-

ity during its operation and make sure that no one can trip over the power
cord.

• The appliance is not splash-proof.

• For indoor use only.

• Do not store the appliance outdoors.

• Store the appliance in a dry place inaccessible to children (pack the ap-

pliance).

• If the supply cord is damaged, it must be replaced by the manufacturer, or

its service agent, or a qualified person in order to avoid a hazard.

• Prior to any maintenance, cleaning and after each use, switch off the ap-

pliance and unplug the mains cable from the socket.

• Repairs to electrical appliances must only be carried out by a qualified

electrical technician.

Assembly (see page 2 and 3)
Attention:

The protection grille must be properly closed prior to switch-

ing on the appliance so as to avoid any damage or hazards. Ensure that all
screws and securing nuts are firmly tightened. Only connect the power cable
to the socket once assembly has been completed.

A. Remove fixing screw (3) on underside of connector (1). Insert connector

(1) into foot (2) and secure with fixing screw for foot and connector (3).

B.  Undo fixing screw (5) on connector (1). Locate motor housing (4) on con-

nector (1) and secure with fixing screw for motor housing and foot (5).

C.  Remove securing nut for grille (6) from motor housing (4) and locate pro-

tection grille rear (7) on motor housing (4). When locating, ensure that
the handle (8) on protection grille rear (7) is on the top. Now screw secur-
ing nut for grille (6) back on to motor housing (4) so as to fix protection
grille rear (7) in position.

D. Attach fan blades (9) to motor housing (4) and secure in position with

fixing screw for fan blades and motor housing (10) (loosely attached to
fan blade). Tighten screw to secure fan blades (9).

E. Locate protection grille front (11) on protection grille rear (7). In doing

so, take care to ensure that positioning clip (12) on protection grille front
