placed by the manufacturer, its service agent or similarly qualified

persons in order to avoid a hazard.

•  This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental ca-

pabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the appliance in

a safe way and understand the hazards involved.

•  Children shall not play with the appliance.

•  Cleaning and user maintenance shall not be made by children

without supervision.

•  Do not immerse the appliance into water for cleaning. Please fol-

low the instructions as stipulated in the chapter “Cleaning”.

Unpacking the Appliance

1.  Remove the appliance from its packaging.

2.

Remove all of the packaging material such as foils, filling

material, cable holders and cardboard packaging.

3.  Check the scope of delivery.

4.  Check the appliance for any transport damage to prevent

a hazard.

NOTE:

There may still be dust or production residues on the

surface of the appliance. We recommend that you quickly

wipe off the housing with a damp cloth.

Scope of Delivery

1× Tower

3×  Pre-assembled Philips screws on the bottom of the

tower

2×  Half base plates

Overview of the Components

1  Speed levels

a  without oscillation

b  with oscillation

2  Timer and on / off switch of the appliance

Assembly Instructions

The appliance must be completely assembled before initial

operation!

NOTE:

•  You will need a Phillips screwdriver of medium size for

the assembly.

•  The screws for the assembly are pre-assembled on

the bottom of the tower.

1.  Place the tower upside down and hold it down.

2.  Unscrew the 3 pre-assembled screws from the bottom of

the tower. Place them within easy reach.

3.

Use the first 2 screws to mount the half of the base plate

with the mains cable guide to the tower.

4.  Feed the power supply cord through the cable guide at

the edge of the base plate.

5.  Insert the other half of the plate into the base plate that is

already mounted to the tower.

6.  Secure the base plate to the tower with a screw.

7.  Place the ventilator with the assembled base plate onto a

stable, level surface.

Start-Up

Electrical Connection

1.  Before inserting the plug into the socket. Make sure that

the mains voltage to be used matches that of the appli-

ance. You can find this information on the nameplate.

2.  Connect the appliance to a duly installed protective

contact socket.
