8
INSTALLATION
• 1
1•2 - ELECTRICAL CONNECTION:
Your hob is supplied with a H05RR-F-
T90 3-core (phase, neutral + earth)
mains cable, section 0,75 mm ²) and
must be connected to a 220-240 V~
single phase mains supply via a phase,
neutral +earth socket meeting standard
IEC 60083 or an omnipolar isolator with
a contact air gap of at least 3.5 mm.
The plug must be accessible after the
hob is installed.
Cross section of the cable to be used
220-240 V˜ - 50 HZ
gas
Cable H05RR-F - T90
Two conductors, One
of which is an earth
Cross section of
conductors in mm²
0,75
The protective conductor (green/
yellow) is connected to the earth
terminal
on the hob and must also
be connected to the installation's earth
terminal
(1.2.1)
.
If the supply cable is damaged, it must
be replaced by a cable or special set
available from the manufacturer or its
after-sales department.
So that you can find the
references for your appliance without
difficulty in the future, we recommend
t h a t y o u m a k e a n o t e o f t h e m o n
page (6.1.1) "After-sales service and
customer relations“ (that page also
tells you where to find them on your
appliance).
1•3 - GAS CONNECTION:
If the hob is to be installed above
an oven or if other nearby heating
appliances could heat and damage the
gas hose, then it is essential that a rigid
pipe is installed instead.
If a flexible hose is used (as is the
case of butane gas) then it must not be
installed in a place where it may be in
contact with a moving part of the kitchen
unit or a location likely to get cluttered.
No flexible hoses with a limited
service life may be longer than 2
metres and must be accessible for
inspection along their entire length.
They must be replaced before their
expiry date (printed on the hose).
Whatever means of connection is
chosen, make sure that it is gastight
when installed, using soapy-water. In
France, you must use a hose or pipe
stamped NF Gaz .
The gas connection must comply with
the regulations in force in the country
where it is installed.
• Mains natural gas
(1.3.1).
Pour votre sécurité, vous devez choisir
exclusivement l’un des 2 raccordements
suivants :
— For your safety, you must choose only
one of the following two connections:
o Connection via a rigid copper
pipe
with
mechanical
s c r e w
connectors (½" gas standard).
• Connect directly on to the elbow on the
appliance.
