Instructions for the user

25

7.2

Hobs with touch-control buttons

When an icon is pressed the unit beeps to confirm.

To operate the panel of the hobs equipped with touch-controls, lightly press the icons printed on its
surface.

On first connection to the electrical mains, an operating check will be carried out automatically
and all the indicator lights will come on for a few seconds.

7.2.1

Switching on the hob

When not in use, all hob components will be switched off. Hold down

 for 2 seconds to switch the

hob on; a led will turn on above the symbol to confirm that the hob is lit. If no functions are used within
30 seconds of switching the hob on, it will automatically turn itself off.

7.2.2

Single cooking zones

The relevant hotplate is indicated next to each control zone. For example, the

 symbol identifies the

knob which controls the rear right-hand cooking zone.
Having switched on the hob as described in “7.2.1 Switching on the hob”, press the

 and

 keys to

activate the hotplate (with the display indicating 0) and adjust the power to the desired operating
setting.
The operating power levels are 1 (lowest) to 9 (highest).
The power must be set within 5 seconds of activating the hotplate as otherwise it will deactivate
automatically.
To activate the hotplate and adjust its power level, press

 and

 as follows:

1.

Press

 (0 appears on the display to indicate that the hotplate has been activated);

2.

Press

 again (9 appears on the display to indicate that the hotplate is active at the maximum

power setting).

3.

Press

 or

 to increase or reduce the power to the desired level (1…9).

7.2.3

Dual cooking zones

To activate heating of the dual cooking zone, once power 9 is reached by following the instructions
provided in paragraph “7.2.2 Single cooking zones”, press the

 again. Now the maximum power of

the cooking zone is activated, and is shown by the LED light turning on next to the number indicating
the operating power. Press on the symbols

 and

 to adjust the power of the dual cooking zone to

the desired value.

7.2.4

Triple cooking zones

To activate heating of the triple cooking zone, once power 9 of the dual cooking zone is reached by following
the instructions provided in paragraph “7.2.3 Dual cooking zones”, press the

 again. Now the maximum

power of the triple cooking zone is activated, and the LED indicating the operating power remains fix. Press
on the symbols

 and

 to adjust the power of the triple cooking zone to the desired value.

7.2.5

Heating zone

This zone, which is present only on some models in the range, keeps the area inside the dashed line
at a temperature of approximately 90°C. It is used for warming dishes up or keeping them hot. If the
hob is not locked, simply press the button

 to switch it on. Press the button

 to switch it off.

7.2.6

Cooking zone lock-out

The cooking zone lock-out function is a user safety functions. It locks out the hob controls to prevent
the ceramic cooking zones being switched on accidentally.
Hold down

 for 1 second to lock out the hob. The hob can be reactivated by holding down

 again

for 1 second.

7.2.7

Cooking zone layout

REAR LEFT

REAR RIGHT

REAR
CENTRAL

CENTRAL

FRONT LEFT

FRONT RIGHT

FRONT
CENTRAL

OVAL
CENTRAL
