USING HOB


Using Gas Burners :

In order to obtain maximum output, be careful that the saucepan which will be used should be

flat bottomed, and use the saucepans with dimensions given herein belove. The valves controlling the gas cookers
have special security mechanism. In order to light the cooker;

1. Always press on the switch forward and bring it to flame symbol by turning anticlockwise (left).
All of the lighters shall operate and the cooker you controlled shall light only. Keep the switch pressed until ignition is
performed. (OPTION)
2. Press on the lighter button by pressing on the switch forward and turning anticlockwise (left). It means Closed
Position.


Rapid Cooker

24 - 28 cm

Semi-rapid Cooker

18 - 22 cm

Aux. Cooker

12 - 18 cm

 Closed

Fully

open

Half

open

In models with Gas Security System, when flame of the cooker is extinguished, control valve cuts off the gas
automatically. (OPTION)

Using Electric Hotplates:
Make adjustment by rotating the switch clockwise according to the heat level you wish to use for your electric cooker.
When the warning lamp lights over the switch, this means that the cooker is engaged. When the cooking is over bring

it back to

     position.


145 mm


LEVEL 1

250 W


LEVEL 2

750 W


LEVEL 3

1000 W

180 mm

500 W

1000 W

1500 W

 Electric Hotplates have standard of 3 temperature levels (as described herein above).depending on your cooker model
that you can use from minimum to maximum temperature. When using first time, operate your electric hotplate in
position 3 for 5 minutes. This will make the agent on your hotplate which is sensitive to heat get hardened by
burning. Use flat bottomed saucepans which fully contact with the heat as much as you can, so that you can use the
energy more productively.


Using Burners :

The our gas ovens top and bottom burner working system is one by one. When you want use your preference burner,
before you must make press the tap knob and wait nearly 5-10 second. Then you can to inflame trought with
automatic ignition or match. You must wait a few second after the inflame to have press by tap knob and after you
can make allow the knob. İf you can not made this operation you must try again.

Using Burners with Flame Failure Device fitted:

Select the burner required, depress and turn the gas control to maximum flame, hold down for 10 to 15 seconds.
once the flame is established the control knob can be released. If the burner fails to stay lit, repeat the procedure, but
increase the length of time the control knob is held down


USING HOB FOR VITROCERAMIC

You operate the hob with the ring switches on the control panel of the hob. This switch regulates the energy in order
to reach the desired temperature which is set by you.
In order to have a good cooking result from the hobs, the pans bottom should be as thick and flat as possible.
The bottom of the pans and cooking zones should be the same size. If possible, always place lids on the pans. Always
place cookware on the cooking zone before it is switched on. To take advantage of the residual heat switch cooking
zones off before the end of the cooking time.
Turn the knob clockwise for starting to operate. Temperature is set up by the knob position on the line gradually
increasing up to max.(Single zone)



Features

140mm hilight 1200W
180mm hilight 1800W
