• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• There is a risk of fire when the

appliance is in connection with an

extension cable, an adapter or a

multiple connection. Make sure that the

ground connection agrees with the

standards and regulations.

• Do not let the power cable to heat up

to a temperature higher than 90° C.

Make sure that you connect

the blue neutral cable to the

terminal with a letter "N" on it.

Connect the brown (or black)

phase cable to the terminal

which has a letter "L". Keep

the phase cable connected at

all times.

8.5

Connection cable

To replace the connection cable use only

the special cable or its equivalent. The

cable type is: H05V2V2-F T90.
Make sure that the cable section is

applicable to the voltage and the working

temperature. The yellow / green earth wire

must be approximately 2 cm longer than

the brown (or black) phase wire.

8.6

Building In

min.
55 mm

min.
650 mm

560 mm

480 mm

min.
450 mm

30 mm

B

A

A)

supplied seal

B)

supplied brackets

CAUTION!

Install the appliance only on a

worktop with flat surface.

8.7

Possibilities for insertion

The panel installed below the hob must be

easy to remove and let an easy access in

case a technical assistance intervention is

necessary.

Kitchen unit with door

min 20 mm
(max 150 mm)

30 mm

60 mm

B

A

A)

Removable panel

B)

Space for connections

Kitchen unit with oven

The electrical connection of the hob and

the oven must be installed separately for

safety reasons and to let easy remove

oven from the unit.
