Warnings:

The induction hob must be installed by a
properly qualified person. We have our own
qualified installers. Never try to install the
appliance yourself.
The induction hob must not be installed above
refrigerators, freezers, dishwashers or tumble
dryers.
The induction hob should be installed so that
optimum radiation of heat is possible.
The wall and the area above the hob should
be able to withstand heat.
To avoid any damage, the sandwich layer
and adhesive should be heat-resistant.

4.

Connection to power supply

The socket should be connected in compliance

with the relevant standard, to a single-pole

circuit breaker. The method of connection is

shown in Figure 3.

Schematic diagram of the control panel

4.Childproof lock key

3.ON/OFF

1.Power/Timer regulating key
2.Boost

Figure (3)

3. Fix the hob to the worktop using the four

    brackets on the base of the hob. The position

    of the brackets can be adjusted according to

    the thickness of the top.

Diagram of induction hob:

If the cable is damaged or needs replacing, this

should be done by an after-sales technician

using the proper tools, so as to avoid any

accidents.

If the appliance is being connected directly to

the mains supply, an omnipolar circuit breaker

must be installed with a minimum gap of 3 mm

between the contacts.

The installer must ensure that the correct

electrical connection has been made and that

it complies with safety regulations.

The cable must not be bent or compressed.

The cable must be checked regularly and only

replaced by a properly qualified person.

(1)

(2)

(3)

(4)

(5)

Control panel

Air vent

Ceramic plate

Air entry

6

1

4

2 3

1

4

2

3

CIB640DV3

CIB640DX

CI

C1640IBDC

CIB1637DC

B640DV3 PM

380-415V 3N~

~
