07 GB

3. USE OF HOB - USER INSTRUCTIONS

This appliance must only be used for the purpose for which it is
intended, domestic cooking, and any other use will be considered
improper and could therefore be dangerous. The Manufacturer will
not be responsible for any damage or loss resulting from improper
use.

3.1. USING THE GAS BURNER

To ignite the burners, place a lighted taper close to the burner, press in
and turn the control knob anti-clockwise.
If the burners have not been used for a couple of days, wait for a few
seconds before lighting the burner, this will allow any air present in the
pipes to escape.
For appliances fitted with electronic ignition carry out the following:
• push in and turn the knob anticlockwise to the ignition symbol.
• ignite the burner by pressing the sparker button.
For hobs fitted with automatic ignition simply push in and turn the knob
to the ignition symbol.
The ignition system will continue to generate sparks as long as the
control knob is being pressed.
If the burner has not ignited within 5 seconds, turn the knob to the 0
position and repeat the operation.
For models fitted with a safety tap (which cuts-off the flow of gas if the
flame is accidentally extinguished) the burners are ignited and
described above, but care must be taken.
Prior to switching on the gas hob ensure that the burners and burner
caps are correctly placed within their position.

GENERAL ADVISE

For best results, use cooking vessels with a flat surface.   The size of
the surface should match the gas burner side as follows. Table A.

For smaller containers the gas burner should be regulated so that the
flame does not overlap the base of the pan. Vessels with a concave or
convex base should not be used.

WARNING: If a flame is accidentally extinguished, turn the knob
to the off position and do not attempt to re-ignite if for at least 1
minute.

If over the years the gas taps become stiff to turn it is necessary to
lubricate them.

Such operation must be carried out only by qualified Service
Engineers.

To prevent any potential damage to the hob please carry out the
installation following this sequence (picture 6):

 1)As illustrated, assemble parts in sequence:

A: 1/2 Male Adaptor Cylindirical
B: 1/2 Seal
C: 1/2 Female Gas Adaptor Conical-Cylindirical or
     Cylindirical-Cylindirical

2)Tighten the joints with the spanner, remembering to twist the
pipes into position.

3)Attach fitting C to mains gas supply using rigid copper pipe or
flexible steel pipe.

IMPORTANT: carry out a final check for leaks on the pipe
connections using a soapy solution. NEVER USE A FLAME. Also,
make sure that the flexible pipe cannot come into contact with a
moving part of the cabinet (eg.adrawer) and that it is not situated
where it could be damaged.

Warning:

If gas can be smelt in the vicinity of this appliance turn off the

gas supply to the appliance and call the engineer directly. Do not
search for a leak with a naked flame.

Table A

Auxiliary

Semi Rapid

Rapid Rear

Burner Type

Ø pan / pot

Max(cm)

AUX
SR
R

18

22

22

Ø pan / pot

Mın (cm)

10

12

20

4. MAINTENANCE AND CLEANING

Before cleaning the hob, ensure the appliance has cooled down.
Remove the plug from the socket or (if connected directly) switch off
the electricity supply.

Cleaning and user maintenance shall not be made by children without
supervision.

Never use abrasives, corrosive detergents, bleaching agents or
acids. Avoid any acid or alkaline substances (lemon, juice, vinegar
etc.) on the enamelled, varnished or stainless steel sections.

When cleaning the enamelled, varnished or chrome sections, use
warm soapy water or a non caustic detergent. For stainless steel use
an appropriate cleaning solution.

The burners can be cleaned with soapy water. To restore their original
shine, use a household stainless steel cleaner. After cleaning, dry the
burners and replace.

It is important the Burners are replaced correctly.

Chromed or Stainless Steel

grids and burners

Chromed or Stainless Steel

grids and burners have a tendency to

discolour with use.   This does not jeopardize the functionality of the
hob.

Our After Sales Service Centre can provide spare parts if required.

5. AFTERCARE

Before calling out a Service Engineer please check the following:
• that the plug is correctly inserted and fused;
• that the gas supply is not faulty.

If the fault cannot be detected:
Switch off the appliance and call the After Service Centre.  DO NOT
TAMPER WITH THE APPLIANCE.

This appliance is marked according to the European
directive 2012/19/EU on Waste Electrical and
Electronic Equipment (WEEE). WEEE contains both
polluting substances (which can cause negative
consequences for the environment) and basic
components (which can be re-used). It is important to
have WEEE subjected to specific treatments, in order
to remove and dispose properly all pollutants, and

recover and recycle all materials.
Individuals can play an important role in ensuring that WEEE does not
become an environmental issue; it is essential to follow some basic
rules:
• WEEE shall not be treated as household waste.
• WEEE shall be handed over to the relevant collection points
managed by the municipality or by registered companies. In many
countries, for large WEEE, home collection could be present.
• When you buy a new appliance, the old one may be returned to the
retailer who has to collect it free of charge on a one-to-one basis, as
long as the equipment is of equivalent type and has the same
functions as the supplied equipment.

6. PROTECTION OF THE ENVIRONMENT

The Manufacturer will not be responsible for any inaccuracy resulting from
printing or transcript errors contained in this brochure. We reserve the right
to carry out modifications to products as required, including the interests of
consumption, without prejiudice to the characteristics relating to safety or
function.

Declaration of compliance:

 This equipment, in the parts intended to

come into contact with food, complies with the regulations laid down in
EEC directives 89/109.
The appliance complies with European Directives 2009/142/EC and
subsequent amendments.

By placing the         mark on this product, we are confirming
compliance to all relevant European safety, health and environmental
requirements which are applicable in legislation for this product.

Rapid Center

R

26

20
