• If the fixing bracket is near to the terminal block, always make sure the connection cable

does not come in contact with the edge of the bracket.

• You must have correct isolation devices: line protecting cut-outs, fuses (screw type fuses

removed from the holder), ground leakage trips and contactors.

Disposal of the appliance

• To prevent the risk of physical injury or damage

– Disconnect the appliance from the power supply.

– Cut off the mains cable where it connects with the appliance and discard it.

– Flat the external gas pipes if there are fitted.

– Speak to your local authorised facilities for disposal of your appliance.

INSTALLATION

WARNING!

The following instructions about installation, connection and maintenance must be carried

out by qualified personnel in compliance with standards and local regulations in force.

Gas Connection

Choose fixed connections or use a flexible pipe in stainless steel in compliance with the reg

-

ulation in force. If you use flexible metallic pipes, be careful they do not come in touch with

mobile parts or they are not squeezed. Also be careful when the hob is put together with an

oven.
Make sure that the gas supply pressure of the appliance obeys the recommended values.

The adjustable connection is fixed to the comprehensive ramp by means of a threaded nut

G 1/2". Screw the parts without force, adjust the connection in the necessary direction and

tighten everything.

1

2

2

3

4

1

End of shaft with nut

2

Washer (additional washer is only for Slovenia and Turkey)

3

Elbow

4

Rubber pipe holder for liquid gas (only for Slovenia and Turkey)

Installation
