Timberk THU UL 26 - Инструкция по эксплуатации - Страница 5

www.timberk.com • electric humidifier

5

5. LIST OF PARTS

1. Air humidifier – 1 pc.
2. Instruction manual and warranty card - 1 pc.
3. Package – 1 pc.

1.  Remove the top cover of the appliance.
2. Fill the tank of about 1.8 liters of water, not higher than the maximum

water level scale «MAX». Also for the fragrance can be added to water

several flavor oil droplets.
3. Install the top cover of the appliance.
4. Plug the power cord into an electrical outlet

Touch the button on / off and intensity of selection the steam from the

backlight.
Used to turn on / off the device, select a pair of output intensity: off, low,

medium, high and control backlit water tank.
The button lights up green when the device of the low-intensity pair of blue

when the unit with an average output intensity pair, red when the device

with high intensity output of steam and flashes red when there is no water.

6. FILLING THE WATER TANK

7. APPLIANCE OPERATION

Control panel

Fig. 2

1

Switching on device

Install the device vertically on a flat, dry surface and then connect the

device to the mains, after filling the tank with water. Press the touch button

« ». The device will turn on with low volume vapor to escape from sprayer

will steam.
At the beginning of this operation, the spraying rate may be unstable, due

to the difference in quality and temperature water. It will take a short time to

ensure that this process is stabilized.

Adjustable steam output intensity

To change the output intensity of the steam press button « » on the

control panel several times, the output intensity of the pair will change: off,

low, medium, high, and the button will light up in different colors.
Comfortable conditions are achieved at a relative humidity air from 40 to

60%. You can determine favorable for you humidity levels for their own

feelings, or use for this special instrument hygrometer (sold separately),

which measures the level of relative humidity.

Automatic shut-off at the places without water

By lowering the water level in the reservoir below the minimum permissible

direct ultrasonic membrane device will automatically shut down, you will

hear a beep and the control panel will button flashes red. To continue the

operation of the device you need to fill the water tank according to claim 6,

«Filling water tank», and then connect the device to an electrical network.

Ionizer

When you turn on the device, an ionizer starts. After 10 minutes, the ionizer

stops working automatically. Turn the unit off and then turn it on again, the

ionizer will be re-run for a further 10 minutes.
The ionizer generates negative ions (anions) and freshens the air in the

room. The anions strengthen the nervous and circulatory system, improve

the activity of the lungs and provide effective protection against respiratory

diseases (such as asthma and pneumonia). The anions purify the air of

dust and smoke.

Color highlighting for the tank water

When you turn on the device lights up lights for the reservoir water, the

colors change in turn.
Press and hold the « »  for 3-5 seconds to lock the desired color.
Press and hold the « » again for 3-5 seconds to cancel color fixation.
Press and hold the « »  for 3-5 seconds for the third time to turn off the

backlight of the tank.
