www.timberk.com • electric humidifier

5

Fig. 2

6. FILLING THE TANK WITH WATER

7. OPERATION OF THE UNIT

1. Remove the tank from the stand and remove the top cover from it.

2. Pour water in the reservoir no higher than the maximum water level

scale «MAX».

3. Install the top tank cover and install it on the stand.

4. Check that the tank on the stand is installed securely, then connect the

plug of the power cord to an electrical outlet.

Set the device strictly vertically on a flat, dry surface, then connect the

device to the electrical network, previously filling the reservoir with water.

Press the on / off button and select the steam output intensity (Fig. 2). The

device will turn on, the light blue work indicator will light up on the control

panel and steam will flow from the sprayer. At the very beginning of this

operation, the level of spraying can be unstable, which is caused by the

temperature difference and water quality. It will take a short time for this

process to stabilize.

Steam output intensity adjustment

In order to change the intensity of the steam output, press the button

on the control panel several times, the intensity of the steam output will

change: off, high, low.

Comfortable conditions are achieved with a relative humidity of 40 to

60%. You can determine the favorable humidity level for you by your own

sensations, or you can use a special hygrometer (not supplied) for this

purpose, which measures the relative humidity level.

Automatic shutdown in the absence of water

If the water level in the tank drops below the minimum permissible level,

the ultrasonic membrane of the device will automatically turn off, while the

red indicator lights up on the control panel. To continue the operation of

the device it is necessary to fill the reservoir with water according to item 6

«Filling the reservoir with water», then connect the device to the electrical

network.

Aroma

The device is equipped with aroma capsules. When you add aromatic oil

to it, air is aromatized. Aromatic oil is not included in the scope of supply.

Switching off the device

To turn off the device, press the button on the control panel several times,

the device will turn off, and the indicator on the control panel will turn off.

8. CLEANING AND MAINTENANCE

Before cleaning the device make sure that the plug is disconnected from

the wall outlet. Otherwise, it may result in electric shock. Before cleaning,

wait until the cooling water in the ground, so as not to burn your hands.

Spend device cleaning once or twice a week. To clean the outer surface of

the unit with a damp soft cloth. To avoid electric shock, do not scratch or

damage the device while cleaning elements.

Do not use when cleaning the device thinner, benzene, dimethyl benzene,

stiff brush, talcum powder and other materials, except water.

Wipe any remaining water inside the base with a damp, soft cloth.

To remove the remaining water in the small details, you can use a soft

brush, then wipe it again with a soft cloth.

In the formation of dirt on the membrane, clean it with a soft brushes. Use

a soft brush to erase the remnants of water on the surface of the device,

and then wipe it again with a soft cloth. Rinse water tank and a clean water

dispenser.

After removal of the residual water from the surface of the sprayer, wipe it

with a soft cloth. Clean the outside surface with a damp, soft cloth.
