www.timberk.com • electric humidifier

5

5. LIST OF PARTS

Control panel for THU UL 20 (BU)

1. Air humidifier – 1 pc.

2. Instruction manual and warranty card - 1 pc.

3. Package – 1 pc.

4. Filter - 2 pc.

6. FILLING THE TANK WITH WATER

1. Remove the water tank cap with the atomizer and then the water tank
itself from the unit.

2. Take the tank handle and pull upwards.

3. Turn over the tank and unscrew the tank cap with the valve and the filter
counterclockwise.

4. Fill the tank with water.

5. Screw the tank cap with the valve and the filter clockwise. Make sure that
the tank cap is tightly secured. Make sure than the rubber ring is installed
on the tank cap. Failure to take all of the above measures may result in air
ingress in the water tank and, as a result, break-down.

6. Install the tank and the water tank cap with the atomizer back to the unit.

Fig. 2

1. On / Off button functions warm steam

2. Steam out flow intensity selector: low, medium, high

3 On / off device

4. On / off function of air ionization

7. APPLIANCE OPERATION

Connect the appliance to the mains, after filling the tank with water.

Press «on / off» on the control panel, the unit will automatically start to
work with this display will light blue button. At the beginning of the spraying
operation level may be unstable, due to the difference in temperature and
water quality.

It will take some time for an ultrasonic conversion membrane was water
vapor and in the process has stabilized. After 10-25 minutes of spraying
level is gradually stabilizing.

In order to change the intensity of the steam release, press the button
(2) on the control panel several times, the output intensity of the pair will
change (low, medium, high). At low intensity burning will display a blue
button with an average intensity of the display will light green button at a
high intensity will burn display bright blue button.

To turn on the air ionization function, press button (4) on the control panel,
and the display will light up this blue button. The ionizer generates negative
ions (anions) and freshens the air in the room. The anions strengthen the
nervous and circulatory system, improve the activity of the lungs and
provide effective protection against respiratory diseases (such as asthma
and pneumonia). The anions purify the air of dust and smoke. To turn off
the air ionization function press again button (4), the display will go out of
the blue button.

To activate the warm steam press (1) on the control panel, with this blue
button lights up the display. When moistened with warm steam heating
water by using the built-in heater. The water in the tank is heated and
passes through atomizer, turning in warm steam. Thanks to the combined
humidification (cold and warm steam) increases the efficiency of the device.
It requires about ten to twenty minutes for spraying hot vapor (the time
required to heat the water heater after inclusion). The average temperature
of the warm vapor is 40 °. Sometimes it is difficult to feel the temperature
of the steam due to a temperature difference tours and ambient humidity.
To turn off the function of warm steam, press the button again (1) will go off
the display of the blue button.

By lowering the water level in the reservoir below the minimum ultrasonic
device will automatically turn off the membrane, you will hear a beep and
the display will turn off all the power button. To continue the operation of
the device is necessary to fill the tank water according to the manual for its
content and connect the device to the mains.

The device is equipped with an aroma capsule. When you add in her

1

2

3

4
