www.timberk.com • electric humidifier

5

5. LIST OF PARTS

Control panel

1. Air humidifier – 1 pc.

2. Instruction manual and warranty card - 1 pc.

3. Package – 1 pc.

6. FILLING THE TANK WITH WATER

1. Remove the water tank cap with the atomizer and then the water tank
itself from the unit.

2. Take the tank handle and pull upwards.

3. Turn over the tank and unscrew the tank cap with the valve and the filter
counterclockwise.

4. Fill the tank with water.

5. Screw the tank cap with the valve and the filter clockwise. Make sure
that the tank cap is tightly secured. Make sure than the rubber ring is
installed on the tank cap.

Failure to take all of the above measures may result in air ingress in the
water tank and, as a result, break-down.

6. Install the tank and the water tank cap with the atomizer back to the unit.

Fig. 2

1. Appliance operation and no water indicator

It is green when the appliance is operating. It is red when there is no water
in the tank.

2. Touch on / off button, and select a couple of output intensity indicator
instrument operation and the lack of water.

Used to turn on / off the device, and select a pair of output intensities: off,
low, high.

The indicator flashes blue when the power is connected, is blue with low
intensity when using the device with low intensity of steam output is blue
with high intensity when using the device with high intensity You are a
running couple, lights up red when there is no water.

1

7. APPLIANCE OPERATION

Switching on

Install the device vertically on a flat, dry surface and then connect the
device to the mains, after filling the tank with water at the same time on the
control panel will flash blue light device operation. Click on the button for
on / off and intensity of the steam to escape. The device is switched on,
the control panel will illuminate in blue with low intensity operation indicator
of the sprayer and will steam.

At the beginning of this operation, the spraying rate may be unstable, due
to the difference in temperature and water quality. It will take a short time to
ensure that this process is stabilized.

Adjustable steam output intensity

In order to change the intensity of the steam press the button on the control
several times, the output intensity of the panel pair will change: off the
low, high, and the button lights up, when operating the device with high
intensity steam output will be brighter than when using the device with
low intensity steam to escape. Comfortable conditions are achieved at a
relative humidity of 40 to 60%. You can define a favorable moisture levels
