www.timberk.com • electric humidifier

5

5. LIST OF PARTS

Control panel

1. Air humidifier – 1 pc.
2. Instruction manual and warranty card - 1 pc.
3. Package – 1 pc.

6. FILLING THE TANK WITH WATER

1. Remove the water tank cap with the atomizer and then the water tank

itself from the unit.
2. Take the tank handle and pull upwards.
3. Turn over the tank and unscrew the tank cap with the valve and the filter

counterclockwise.
4. Fill the tank with water.
5. Screw the tank cap with the valve and the filter clockwise. Make sure

that the tank cap is tightly secured. Make sure than the rubber ring is

installed on the tank cap.
Failure to take all of the above measures may result in air ingress in the

water tank and, as a result, break-down.
6. Install the tank and the water tank cap with the atomizer back to the unit.

Fig. 2

1. The power indicator.

Lights green if the power supply unit.
2. Indicator instrument operation and the lack of water. It illuminates green

when operating the device. Solid red color in the absence of water. Flashing

red in standby mode.
3. ON / OFF button and select the output intensity couple. Used to turn

on / off the device, and select a pair of output intensities: high, medium,

low, off.

7. APPLIANCE OPERATION

Switching on

Set the instrument to the true vertical on a flat, dry surface and then plug

it into the power line, filling the tank with water first. Click off and intensity

control / outflow of steam all the way to the right. The device is switched

on, the green LED work lights on the control panel and the steam will begin

to flow from the sprinkler. At the very beginning of the level of atomization

may seem unstable, due to the difference in temperature and water quality.

It takes a bit of time to the process of stabilization.

Adjust steam outflow rate

You can adjust the intensity of steam by pressing the on / off button.

Humidifier power operates in three modes, switching to use the on / off

key: OFF, high, medium, low. In the absence of the water turns red. Enable

or disable the button is made of soft rubber. Comfortable conditions

are achieved at 40 to 60% relative humidity. You can define the level of

humidity, favorable to you or according to your feelings, or using a special

device called a hygrometer (not supplied), the measurement of the relative

humidity level.

1

2

3
