www.timberk.com • electric humidifier

5

Control panel for THU UL 15M (SV), THU UL 15M (GR), THU UL 15M (VT),

THU UL 15M (BE), THU UL 15M (WB)

Control panel for THU UL 15E (SV), THU UL 15E (BL)

1. Appliance operation and no water indicator

It is blue when the appliance is operating. It is red when there is no water

in the tank.
2. On/Off and steam outflow intensity control knob

It is used to switch the appliance on/off and to adjust the steam outflow

intensity.

1. On/Off button

2. Steam outflow indicators

3. Timer indicators (TIMER): switching off in 1h, 2h, 4h, 8h

4. Switch off timer setting button

5. Current temperature value (TEMP)

6. SLEEP mode indicator

7. SLEEP mode activation button

8. No water indicator

9. Steam outflow intensity selection button

10. Appliance operation mode indicator

1

3
2

4

5

6

7

8

9

10

2

1

1. Air humidifier – 1

2. Instruction manual and warranty card - 1

3. Package - 1

Always unplug the unit before removing the water tank. Do not touch the

water in the base during operation.
• Remove the water tank from the base and unscrew the water tank cap.
• Make sure that no foreign objects are in the water tank.
• Fill the tank with clean, cold water from the tap. Close the cap of the

water tank securely, place the water tank onto the base.
• Do not pour water into the mist outlet of the appliance.
• Insert the plug into the socket and switch on the appliance using the on/

off dial.

5. LIST OF PARTS

6. FILLING OF TANK WITH WATER

7. APPLIANCE OPERATION

Operation of THU UL 15M model

Switching on

Install the appliance to a true vertical on an even and dry surface, then

connect it to the power line, having filled the tank with water first. Turn

the on/off and steam outflow intensity knob all the way to the right. The

appliance will switch on, the blue operation indicator will light up on the

control panel and steam will start coming from the atomizer. At the very

beginning of operation, the atomizing level may appear unstable, which is

caused by the temperature difference and water quality. It will take short

time for this process to stabilize.

Adjusting steam outflow intensity

You can adjust steam intensity by turning the on/off and steam outflow intensity

knob to the left or right.
Comfortable conditions are reached at 40 to 60% relative air humidity. You can

determine the humidity level favorable for you either according to your feelings

or by using a special device called a hygrometer (not included in the scope of

supply), measuring the relative humidity level.
