Timberk THU UL 14 E - Инструкция по эксплуатации - Страница 5

www.timberk.com • electric humidifier

5

Air ionization function

To turn the air ionization function on or off, press the --- button. When

the button is pressed, the negative ion generator turns on / off, and the

ionization indicator on the control panel lights up / goes out.

The ionizer generates negatively charged ions (anions) and refreshes the

air in the room. Anions strengthen the nervous and circulatory system,

improve lung function and serve as effective protection against respiratory

diseases (such as asthma and pneumonia). Anions clean the air of dust

and smoke.

Humidity control function

When this function is activated, the device will automatically turn off when

reaching the set humidity level (more than 3%) and automatically turn on

when the humidity level falls below the set humidity level.

To activate the humidity control function, press the --- button. The display

shows the set humidity value. Continue to press the --- button to set the

desired humidity level from 20% to 85% in 5% increments and select the

desired humidity level. After setting, the set value flashes in the display for

3 seconds, after which the value of the current humidity is displayed. Press

6.APPLIANCE OPERATION

1

15

10

14

11

13

12

9

2

8

3

5

4

6

7

1.   Power  on / off button
2.   Steam output selection button: low, medium, high
3.   Automatic power on / off button
4.   Symbol of humidity
5.   Automatic mode indicator
6.   Steam output indicators
7.   Button setting the desired level of humidity from 20 to 85%
8.   Set timer button to turn off the device
9.   Air ionization on / off  button
10. Timer indicator
11. Air ionization indicator
12. The display
13. Indicator of absence of water
14. The symbol of the hour
15. Light indication of operating modes

Switching the device on

Fill the reservoir with water and install the device vertically on a flat, dry

surface, then connect the appliance to the mains by inserting the plug of

the power cord into an outlet.

Press --- button, the device will automatically start to work and the display

will show the steam output indicators, the current humidity value, and the

mode light will light around the control panel.

At the very beginning of the work, the level of spraying can be unstable,

due to the difference in temperature and water quality. It will take some time

for the water to vaporize on the ultrasonic membrane, and this process

has stabilized. After 10-25 minutes of operation, the spray level gradually

stabilizes.

Steam output intensity adjustment

In order to change the intensity of the steam output, press the button ---

several times, the intensity of the steam output will change: low, medium,

high, and accordingly the intensity of the steam output will be indicated by

the indicators on the display and the intensity of the light indications of the

modes around the control panel.

Comfortable conditions are achieved with a relative humidity of 40 to 60%.

ATTENTION!

If the device generates a large amount of condensate

on the top of the device and on objects near it, it is

necessary to reduce the intensity of the steam output.
