Yamaha RX-V463 - Инструкция по эксплуатации - Страница 63

61

 En

SET MENU

English

AD
V

ANCED

OPERA

T

ION

Maximum volume

MAX VOL.

Use this feature to set the maximum volume level. This
feature is useful to avoid the unexpected loud sound by
mistake. For example, the original volume range is –80 dB
to +16 dB. However, when “MAX VOL.” is set to –5 dB,
the volume range becomes –80 dB to –5 dB.

Control range: –30 dB to +10 dB,

 +16 dB

Control step: 5 dB

The “MAX VOL.” setting takes priority over the “INIT.VOL.”
setting. For example, if “INIT.VOL.” is set to –20 dB and “MAX
VOL.” is set to –30 dB, the volume level is automatically set to
–30 dB when you turn on the power of this unit next time.

Initial volume

INIT.VOL.

Use this feature to set the volume level when the power of
this unit is turned on.
Choices:

OFF

, MUTE, –80 dB to +16 dB

Control step: 1 dB

The “MAX VOL.” setting takes priority over the “INIT.VOL.”
setting.

■

HDMI set

H)HDMI SET

Use this feature to select the component to play back
HDMI audio signals.

Support audio

SUPPORT AUDIO

Use this feature to select whether to play back HDMI
audio signals on this unit or on another HDMI component
connected to the HDMI OUT jack on the rear panel of this
unit.

• This unit transmits audio and video signals input at the HDMI

input jacks to the HDMI out jack only when this unit is turned
on even if “SUPPORT AUDIO” is set to “Other”.

• Available audio/video signals depend on the specification of the

connected video monitor. Refer to the instruction manual of
each connected component.

Note

Note

Choice

Functions

RX-V463

Plays back HDMI audio signals on this unit. The
HDMI audio signals input at the HDMI input
jacks of this unit are not output to the HDMI
component connected to the HDMI OUT jack on
the rear panel of this unit.

Other

Plays back HDMI audio signals on another
HDMI component connected to the HDMI OUT
jack.

Notes

H)HDMI SET

SUPPORT AUDIO:

RX-V463

[ ]/[ ]:Select

p

[

[ENTER]:Return

1 SOUND MENU
