18

 En

Connections

Connect the audio components as follows.

■

Connecting a CD player and a CD
recorder/MD recorder

• When you connect your CD player via analog and digital

connection, priority is given to the signal input at the DIGITAL
INPUT jack.

• To make a digital connection to a component other than the

default component assigned to each DIGITAL INPUT jack,
select the corresponding setting in “INPUT ASSIGNMENT”
(see page 62).

■

Connecting a multi-format player or an external decoder

This unit is equipped with 6 additional input jacks (FRONT L/R, SURROUND L/R, CENTER and SUBWOOFER) for
discrete multi-channel input from a multi-format player, external decoder or sound processor. Connect the output jacks
on your multi-format player or external decoder to the MULTI CH INPUT jacks. Be sure to match the left and right
output jacks to the left and right input jacks for the front and surround channels.

• When you select the component connected to the MULTI CH INPUT jacks as the input source (see page 34), this unit automatically

turns off the digital sound field processor, and you cannot select sound field programs.

• This unit does not redirect signals input at the MULTI CH INPUT jacks to accommodate for missing speakers. We recommend that

you connect a 5.1-channel speaker system before using this feature.

Connecting audio components

Make sure that this unit and other
components are unplugged from the
AC wall outlets.

Notes

indicates recommended connections

indicates alternative connections

Notes

MONITOR

OUT

L

R

DTV/CBL

DVR

DVD

MD/

CD-R

OUT

(REC)

IN

(PLAY)

OUT

IN

DTV/CBL

DVR

DVD

OUT

IN

CD

L

R

W

SURROUND

MULTI CH INPU

AUDIO

VIDEO

FRONT

1

2

3

DTV/CBL

DTV/CBL

CD

OUT

DVD

DVD

OPTICAL

COAXIAL

DVD

P

R

P

B

Y

P

R

MONITOR OUT

COMPONENT VIDEO

HDMI

DIGITAL INPUT

VIDEO

IN1

IN2

L

R

MD/

CD-R

OUT

(REC)

IN

(PLAY)

CD

AUDIO

3

CD

OPTICAL

DIGITAL INPUT

L

R

O

R

L

L

R

CD player

CD recorder or

MD recorder

Audio out

Optical out

Audio in

Audio out

FRONT

CENTER

SURROUND

SUB

WOOFER

L

R

MULTI CH INPUT

L

R

L

R

Sub

w

oofer

 o

u

t

Multi-format player/
External decoder

Cent

er

 o

u

t

Surr

o

und o

u

t

Fr

on
t ou
t
