11

 En

Connections

English

PRE

P

ARA

T

ION

Be sure to connect the left channel (L), right channel (R), “+” (red) and “–” (black) properly. If the connections are faulty,
this unit cannot reproduce the input sources accurately.

Connecting speakers

Caution

•

Before connecting the speakers, make sure that the AC power plug is disconnected from the AC wall outlet.

•

Do not let the bare speaker wires touch each other or let them touch any metal part of this unit. This could damage
this unit and/or the speakers. If the speaker wires are short-circuited, “CHECK SP WIRES” appears in the front
panel display when you turn on this unit.

•

Use the magnetically shielded speakers. If this type of speaker still creates interference with the monitor, place the
speakers away from the monitor.

L

R SURROUND

L

R

FRONT B

L

R

FRONT A

CENTER

MONITOR

OUT

L

R

DTV/CBL

DVR

DVD

MD/

CD-R

OUT

(REC)

IN

(PLAY)

OUT

IN

DTV/CBL

DVR

DVD

OUT

IN

CD

L

R

SUB

WOOFER

SUB

WOOFER

SURROUND

CENTER

MULTI CH INPUT

AUDIO

VIDEO

OUTPUT

FRONT

1

2

3

DTV/CBL

DTV/CBL

CD

OUT

DTV/CBL

DVR

DVD

DVD

OPTICAL

COAXIAL

DVD

P

R

P

B

Y

P

R

P

B

Y

MONITOR OUT

AM

GND

FM

75

UNBAL.

COMPONENT VIDEO

ANTENNA

SPEAKERS

HDMI

DIGITAL INPUT

VIDEO

DOCK

IN1

IN2

Front speakers

(FRONT A)

Surround speakers

Subwoofer

Center

speaker

Left

Left

Right

Right

FRONT B terminals

Connect the alternative front speaker system
(FRONT B).
