RX-E810

AMPLIFIER SECTION

• Minimum RMS output power per channel

(6

Ω

, 1 kHz, 0.1% THD) .........................................  55 W + 55 W

• Maximum RMS output power per channel

(6

Ω

, 1 kHz, 1% THD) ............................................  65 W + 65 W

• Input sensitivity/Impedance

DVD/MD/TAPE/AUX etc. ..................................... 150 mV/47 k

Ω

• Frequency Response (20 Hz to 20 kHz)

DVD etc. ........................................................................ 0 ± 0.5 dB

• Total Harmonic Distortion (20 Hz to 20 kHz)

DVD etc. 30 W, 6

Ω

..................................................  0.04% or less

• Signal to Noise ratio (IHF-A network)

DVD etc. (150 mV, Input shorted) ........................... 93 dB or more

• Output level/Impedance

PHONES....................................................................0.23 V/120

Ω

TUNER SECTION

FM Section

• Tuning Range

U.S.A., Canada, Asia, and Taiwan models

.........................................................................  87.50-107.90 MHz

Other models....................................................  87.50-108.00 MHz

AM Section

• Tuning Range

U.S.A., Canada, Asia, and Taiwan models ...............530-1710 kHz
Other models.............................................................531-1611 kHz

• Sensitivity

FM (S/N 68 dB) ..................................................................  6.0

µ

V

AM .................................................................................  600

µ

V/m

GENERAL

• Power Supply

U.S.A. and Canada models .................................. AC 120 V, 60 Hz
Australia model.................................................... AC 240 V, 50 Hz
U.K. and Europe models...................................... AC 230 V, 50 Hz
Korea model......................................................... AC 220 V, 60 Hz
China model......................................................... AC 220 V, 50 Hz
Asia model ............................................... AC 220-240 V, 50/60 Hz
Taiwan model........................................... AC 110-120 V, 50/60 Hz

• Power consumption

U.S.A., Canada, and Taiwan models .................................... 115 W
Other models......................................................................... 130 W

• Standby Power consumption .................................................... 0.1 W
• AC Outlets

U.K. and Australia models............................ 1 (Total 100 W max.)
Korea model............................................................................ None
Other models................................................. 2 (Total 100 W max.)

• Dimensions (W x H x D) .................................. 215 x 108 x 363 mm
• Weight .......................................................................................5.7 kg

■

DVD-E810

PLAYBACK SYSTEM

• DVD video, video CD and SVCD, CD, picture CD, CD-R/RW,

DVD+R/RW, DVD-R/RW

VIDEO PERFORMANCE

• Video (CVBS) Output.............................................. 1 Vpp into 75

Ω

• S-Video output ..................................................... Y: 1 Vpp into 75

Ω

C: 305 mVpp into 75

Ω

• RGB (Scart) output ........................................... 700 mVpp into 75

Ω

• Component video output...................................... Y: 1 Vpp into 75

Ω

P

B

C

B

P

R

C

R

: 700 mVpp into 75

Ω

AUDIO FORMAT

• Dolby Digital/DTS/MPEG ................................. Compressed Digital

PCM ......................................................................... 16, 20, 24 bits

fs, 44.1, 48, 96 kHz

MP3 (ISO 9660) ..........................................96, 128, 256, 320 kbps

fs, 32, 44.1, 48 kHz

WMA................................................................. 64 kbps - 192 kbps

fs, 44.1, 48 kHz

• Analog Sound ............................................................................stereo

LASER

• Type ..................................................... Semiconductor laser GaAlAs
• Wave length ................................................................ 650 nm (DVD)

780 nm (VCD/CD)

• Output power ................................................................ 7 mW (DVD)

10 mW (VCD/CD)

• Beam divergence .................................................................60 degree

AUDIO PERFORMANCE

• DA Converter ............................................................. 24 bit/192 kHz
• Signal-Noise (1 kHz)...............................................................105 dB
• Dynamic range (1 kHz) .............................................................97 dB
• DVD

fs 96 kHz

2 Hz - 44 kHz

fs 48 kHz

2 Hz - 22 kHz

• SVCD

fs 48 kHz

2 Hz - 22 kHz

fs 44.1 kHz

2 Hz - 20 kHz

• CD/VCD

fs 44.1 kHz

2 Hz - 20 kHz

• Distortion and Noise (1 kHz) .............................................. 0.0035 %

TV STANDARD (PAL/50 Hz) (NTSC/60 Hz)

• Number of lines

625

525

• Playback

Multistandard

(PAL/NTSC)

CONNECTIONS

• SCART ........................................................................Euroconnector
• Y output........................................................................ Cinch (green)
• P

B

/C

B

 output .................................................................... Cinch (blue)

• P

R

/C

R

 output ...................................................................... Cinch (red)

• S-Video output ........................................................Mini DIN, 4 pins
• Video output ..............................................................................Cinch
• Audio output (L+R) ..................................................................Cinch
• Digital output

...................... 1 coaxicial, 1 optical (IEC60958 for CDDA/LPCM)

(IEC61937 for MPEG2, Dolby Digital)

GENERAL

• Power supply

U.S.A. and Canada models .................................. AC 120 V, 60 Hz
Australia model .................................................... AC 240 V, 50 Hz
U.K. and Europe models ...................................... AC 230 V, 50 Hz
Korea model ............................................ AC 110-240 V, 50/60 Hz
China model ......................................................... AC 220 V, 50 Hz

• Standby Power consumption ................................................. < 1.0 W
• Power consumption ..................................................... Approx. 12 W
• Dimensions (W x H x D) .................................. 215 x 108 x 330 mm
• Weight ...................................................................................... 2.3 kg

*Specifications are subject to change without notice.
