45

GB

Other Operations

Recording

Your receiver makes it easy to record to and from the
components connected to it. You don’t have to connect the
playback and recording components directly to each
other: once you select a program source on the receiver,
you can record and edit as you normally would using the
controls on each component.

Before you begin, make sure you’ve connected all
components properly.

ç

:  Audio signal flow

c

:  Video signal flow

Recording on an audio tape or MiniDisc

You can record on a cassette tape or MiniDisc using the
receiver. Refer to the instruction manual of your cassette
deck or MD deck if you need help.

1

Select the component to be recorded.

2

Prepare the component for playing.

For example, insert a CD into the CD player.

3

Insert a blank tape or MD into the recording deck
and adjust the recording level, if necessary.

4

Start recording on the recording deck, then start
playback on the playback component.

Notes

• You cannot record a digital audio signal using a component

connected to the analog MD/TAPE REC OUT jacks.

• Sound adjustments do not affect the signal output from the

MD/TAPE REC OUT jacks.

RDS EON RDS PTY

SOUND FIELD

MULTI CHANNEL DECODING

MASTER VOLUME

DISPLAY

INPUT MODE

VIDEO

MD/TAPE

CD

TUNER

AUX

DVD/LD

TV/SAT 5.1CH INPUT

CINEMA STUDIO

LEVEL

I

–

i

+

SET UP

BASS BOOST

TONE

FM/AM

MUTING

TONE

BASS

BOOST

SHIFT

MEMORY

FM MODE

–   TUNING   +

NAME

ENTER

SUR

BASS/

TREBLE

SOUND FIELD

A. F. D.

A

B

C

2CH

MODE

DIMMER

SPEAKERS

R

 ON

r

 OFF

A

PHONES

B

?

/

1

PRESET/

–   PTY SELECT   +

Naming Preset Stations and
Program Sources

You can enter a name (index name) of up to 8 characters
for preset stations and program sources. These names (for
example, “VHS”) appear in the receiver ’s display when a
station or program source is selected.
Note that no more than one name can be entered for each
preset station or program source.
This function is useful for distinguishing components of
the same kind. For example, two VCRs can be specified as
“VHS” and “8MM”, respectively. It is also handy for
identifying components connected to jacks meant for
another type of component, for example, a second CD
player connected to the MD/TAPE jacks.

1

To name a preset station

Press TUNER.

The last station you received is tuned in.

To name a program source

Select the program source (component) to be
named, then go to Step 3.

2

Tune in the preset station you want to create an
index name for.

If you are not familiar with how to tune in preset
stations, see “Tuning to preset stations” on page 41.

3

Press NAME.

4

Create an index name by using the jog dial and
cursor buttons:

Turn the jog dial to select a character, then press

 to

move the cursor to the next position.

To insert a space

Turn the jog dial until a blank space appears in the
display (you can find the space character between “

]

”

and “A”).

If you’ve made a mistake

Press

 or

 repeatedly until the character to be

changed flashes, then turn the jog dial to select the
right character.

5

Press ENTER.

To assign index names to other stations

Repeat Steps 2 to 5.

Note

You cannot change the name of an RDS station.

Playback component

(program source)

c

ç

ç

c

Recording component
(tape deck, MD deck,
VCR)

Function buttons
