2-in-1 Grass Trimmer/Edger

EN

15

14

ACCESSORIES

WG163E WG163E.1 WG163E.9

Flower guard

1

1

1

Charger

1

(WA3760)

1

(WA3760)

/

Battery pack

2

(WA3551.1)

1

(WA3551)

/

Spool (WA0004)

1

1

1

Safety guard

1

1

1

Edger wheel

1

1

1

We recommend that you purchase your accessories

from the same store that sold you the tool. Refer to

the accessory packaging for further details. Store

personnel can assist you and offer advice.

ASSEMBLY AND OPERATION

NOTE:

Before using the tool, read the

instruction book carefully.

Intended Use

The machine is intended for the cutting of grass and

weeds under bushes, as well as on slopes and edges

that can not be reached with the lawn mower.

WARNING!

 The charger and battery pack are

specially designed to work together so do not

attempt to use any other devices. Never insert or

allow metallic objects into your charger or battery

pack connections because of an electrical failure and

hazard will occur.

WARNING!

 Always wear the eye protection.

Never lean over the trimmer head. Rocks or

debris can ricochet or be thrown into eyes and face

and cause blindness or other serious injury. When

operating unit, check for the following:

Wear eye protection and heavy clothing. Hold front

handle with one hand and auxiliary handle with

the other hand. Keep unit below waist level. Work

only from your right to your left to ensure debris is

thrown away from you. Without bending over, keep

line near and parallel to the ground (perpendicular

when edging) and not crowded into material being

cut.

WARNING!

Make sure that line is fed out

before operation. Make sure motor is up

to full speed before trimming or edging.

WARNING!

Only use 1.65mm diameter

cutting line.

 Other sizes of line will not feed

properly and will result in improper cutting head

function or can cause serious injury. Do not use other

material such as wire, string, rope, etc. Wire can

break off during cutting and become a dangerous

projectile that can cause serious injury.

ASSEMBLY & OPERATION

Action

Figure

Assembly

Assembling the Safety Guard

See Fig. A1, A2

Mounting the Edger Wheel

WARNING: Make Sure

the ON/OFF Switch

is Locked Off to Prevent

Accidental Starting.

See Fig. B

Installing and Removing the

Battery Pack

See Fig. C

Charging the battery pack

More details can be found in

charger’s manual

See Fig. D1

Checking the battery condition

(Only for WG163E.1 )

See Fig. D2

Operation

Safety ON/OFF Switch

WARNING!

The cutting

head continues to rotate

after the trimmer has been

switched off; wait until it has

completely stopped then lay down

the tool.

See Fig. E

Trimming

- Adjusting the Shaft

WARNING!

Make Sure the

ON/OFF Switch is Locked

Off to Prevent Accidental Starting.

See Fig. F

- Adjusting the Trimmer Head

See Fig. G1, G2

- Adjusting the Auxiliary handle

See Fig. H

- Trimming

See Fig. I1

- Using the Flower Guard

See Fig. I2

Edging

- Changing the tool into the
Edging mode

See Fig. J1, J2

- Edging

See Fig. K

Command feeding the line

See Fig. L

Manually feeding the line

See Fig. M
