ETR 750 - ETR 900J

15

ENGLISH

6. A

SSEMBLY

INSTRUCTIONS

M

OUNTING

THE

GRIP

1

F

IG

. 2

Press the grip on the tube until it goes into
place, keeping the inclined part of the grip facing
the motor.
Slide the grip along the rod until it reaches a
comfortable height.
Fit the screw (A) into the grip, fit the washer (B)
and tighten the wing nut (C).

M

OUNTING

THE

GUARD

1

F

IG

. 3

Attach the guard to the tube, with the guard fac-
ing the opposite side of the motor (A), and slide
it until it leaves the clamp and lies over the alu-
minium head (B).
Rotate the guard by 180° and position it in its
seat on the aluminium head (C).
Position the guard extension (D).
Fit the Ø4.3x9 washers and insert the M4x14
screws.
Tighten the screws with the supplied wrench (E).

WARNING:

 Perform the operation taking care not to

knock the cord cutter as this may cause injuries!

ATTENTION:

 Never work without the guard. The

guard must always be fitted with the cord cutter!

M

OUNTING

/

DISMOUNTING

THE

CUTTING

ASSEMBLY

 (

FOR

DISMOUNTABLE

MODELS

)

1

F

IG

. 4

Align the release button (A) with the hole in the
guide (B) to simplify installation.
Hold the dismountable cutting assembly firmly
and push it into the clamp until the release but-
ton (A) enters the hole in the clamp (B).
Tighten the knob (D) (right-hand thread). Make
sure it is perfectly tight before using the unit.

To dismount the cutting assembly, proceed in re-
verse order:

Loosen the knob (D) (right-hand thread).
Press down on the release button (A).
Slide the cutting assembly off the clamp.

7. P

REPARATION

C

LOTHING

Never use the appliance barefooted or wearing
sandals. Never use the appliance when wearing
loose clothing that could get caught up in it. When
working, wear long trousers, safety boots or shoes
with non-slip soles, goggles and a shield protecting
your face from flying objects, gloves (preferably
leather) and anti-noise ear muffs or helmet. In work
areas where there is a risk of falling objects, pro-
tect your head with a safety helmet.

E

LECTRICAL

CIRCUIT

1

F

IG

. 5

Before connecting the appliance to the electricity
supply, check that the mains voltage and fre-
quency are compatible with the operating voltage
and frequency of the machine (see rating plate).
Connect the machine to a socket with differential
switch (circuit breaker) using an approved outdoor
cable. Always fix the extension cable (A) to the

cable holder located on the motor casing.

ATTENTION:

 To protect the electrical connection, do

not tug on the cable when using the appliance and
grip the plug and socket when disconnecting the ca-
ble.

8. U

SE

S

COPE

Use the edge trimmer fitted with just the cord head
to cut grass – especially around obstacles – and to
trim thin weeds and wild vegetation near ground
level. The cord head is particularly suitable for fin-
ishing operations such as trimming around posts
and trees.

ATTENTION:

 The standard version of the brush cutter

cannot be used in other ways.

A

DJUSTING

THE

LENGTH

OF

THE

NYLON

CORD

Always check the length of the cord in the supplied
head before use. This head features a semi-auto-
matic system for adjusting cord length. When the
cord is short, start the machine and hit the cord
head on soft ground a few times. The cord comes
out automatically. Excessive cord length is cut by
the adjustment blade mounted on the guard.

R

ECOMMENDATIONS

FOR

USE

1

F

IG

. 6

Observe the relevant safety instructions when
using the brushcutter.
Carry the power tool on your r.h. side.
Approach the area to be cleared with the motor
switched OFF; then start the motor before dip-
ping the cutter into the working area.
With your thumb, initially press the locking but-
ton (1) and then additionally the ON/OFF switch
(2) with your index finger. Then release the lock-
ing button again. Release the ON/OFF switch to
switch the motor OFF again.
Work at a regular pace and move from side to
side as though you were using a traditional
scythe. Do not incline the cord head while work-
ing. Try and cut a small area to the right height.
Keep the cord head at the same distance from
the ground in order to obtain a uniform cutting
height.
Immediately switch OFF the motor, if you notice
any unusual vibrations or cuttings have wrapped
themselves around the cutting tool or have
jammed near the guard. Pull the mains plug
from its socket and clear the cutting tool of
grass, brush etc.
Check the entire power tool for perfect condi-
tion.
When using the nylon head, always ensure that
you operate only with the correct length of line.
When the guard is fitted, the line will always be
trimmed to the permissible length automatically
(a line trimming blade is fitted into the guard
bar).
