Fig.21

CAUTION:

•

Do not force the trimmer in densely growing grass.

Fig.22

CAUTION:

•

Do not use the trimmer as if you dig out the
ground with it.

Cutting the grass near a tree, concrete block,
brick or garden stone

Fig.23

Hold the trimmer tilting at a level so that it does not contact the
ground surface and cut the grass using the Nylon cord tip like
knocking the ground. In this work, smooth feeding out is
needed because the Nylon cord wears more quickly than usual.

NOTE:

•

Getting the trimmer too close to a tree, concrete
block, brick or garden stone or the like during
performing the edging work or such similar cutting
work may cause the Nylon cord to be cut off halfway
inside the spool cover. At this time, take the spool out
of the spool cover and then set the Nylon cord again
properly by referring to the section titled "Installing or
removing the Nylon cutting head" and "Winding a
new Nylon cord on the spool". Using the tip of the
Nylon cord during operation brings the best result of
operation and therefore it is recommended to keep
the tool more than 5 cm away from the tree, concrete
block, brick or garden stone or the like.

Start the trimmer before getting close to the grass to be cut.
Cut the grass using the Nylon cord tip by moving the
trimmer from right to left and proceed slowly, keeping
the trimmer tilted at the angle of about 30

ﾟ

 in relation

to the ground surface.
When cutting high grass, cut in layers always beginning
from the top with each cut length short.

Using the tool as an edger

Fig.24

Using the tool as an edger allows the operator to cut
along the edge of the concrete block, brick and the like.

Fig.25

For using the tool as an edger, hold the shaft of the trimmer
with one hand and turn the grip counter clockwise to loosen
the shaft. Rotate the shaft with the motor housing 180

ﾟ

 and

tighten the grip clockwise until it locks.

NOTE:

•

Before rotating the shaft, it needs to be fully
shortened or extended.

•

After changing to the edger position, make sure
that the motor housing and shaft are locked.

Fig.26

To obtain a good result of finish cutting, move parallel to
the edge you are going to perform an edging work.

Cutting the grass in a tight place or on a
slope

WARNING:

•

When cutting the grass on a slope, be careful of
stones, grass and other foreign objects thrown
from the cutting head area.

•

When cutting the grass on a slope, make sure that
you always keep a good and stable footing.

Fig.27

To ease the work in a tight place which restricts the
height, such as cutting the grass under an outdoor wood
deck and similars, push the lock button and then bend
down the cutting head so that the shaft is parallel to the
ground surface. Adjusting the cutting head angle
properly in this way helps you cut the grass on a slope.

MAINTENANCE

WARNING:

•

Always be sure that the tool is switched off
and battery cartridge is removed before
attempting to perform inspection or
maintenance on the tool.

 Failure to switch off

and remove the battery cartridge may result in
serious personal injury from accidental start-up.

NOTICE:

Never use gasoline, benzine, thinner, alcohol or
the like. Discoloration, deformation or cracks may
result.

To maintain product SAFETY and RELIABILITY, repairs,
any other maintenance or adjustment should be
performed by Makita Authorized Service Centers,
always using Makita replacement parts.

OPTIONAL ACCESSORIES

CAUTION:

•

These accessories or attachments are
recommended for use with your Makita tool
specified in this manual. The use of any other
accessories or attachments might present a risk of
injury to persons. Only use accessory or
attachment for its stated purpose.

If you need any assistance for more details regarding
these accessories, ask your local Makita Service Center.

•

Nylon cutting head

•

Nylon cords

•

Shoulder strap

•

Goggles

•

Makita genuine battery and charger

NOTE:

•

Some items in the list may be included in the tool
package as standard accessories. They may differ
from country to country.
