4

GB

c o n s i d e r e d   i m p r o p e r   a n d   t h e r e f o r e   a
source of risk to people and property.

PROTECTIVE CLOTHING

While working with the brushcutter,

always use safety protective approved
clothing.

 The use of protective clothing does

not eliminate injury risks, but reduces the injury
effects in case of accident. Consult your trusted
supplier to choose an adequate equipment.

The clothing must be proper and not an obstacle.
Wear adherent protective clothing.

Protective

jackets and dungarees are ideal.

 Do not wear

clothes, scarfs, ties or bracelets that can stuck
into twigs. Tie up and protect long hair (example
with foulards, caps, helmets, etc.).

Safety shoes having skid-proof sole and anti-
piercing insert.

Wear protective goggles or face screens!

Use protections against noises; for example
noise reduction ear guards or earplugs.

The

use of protections for the ear requests much
more attention and caution, because the
perception of danger audio signals (screamings,
alarms, etc.) is limited.

Wear gloves that permit the maximum
absorption of vibrations.

2. SYMBOLS AND SAFETY WARNINGS (Fig.21)

  1  - Read operator’s instruction book before

operating this machine.

  2  -  Wear head, eye and ear protection.
  3  -  Wear strong boots and gloves when cutting

with metal or plastic blades.

  4  -  Be aware that objects can be thrown.
  5  -  Keep bystanders away 15 m.
  6   -

WARNING!

 – The surface can be hot!

  7  -  Warning! Kickback it’s danger.
  8   -  Purge Bulb.
  9 -  Type of machine:

BRUSH CUTTER

.

 10 -   Guaranteed sound power level.
 11 -   CE conformity marking.

 12 -   Serial number.
 13 -  Year of manufacture.
 14 -  Max. speed of output shaft, RPM

3. MAIN COMPONENTS (Fig.1)

 1÷2 - Tools supplied
  3 -  Harness
  4  -  Bevel gear
  5  -  Curved guard
  6  -  Nylon line head
  7  -  Fuel tank cap
  8 -  Purge Bulb
  9  -  Carburettor adjustment screws
  10  -  Muffler guard
  11  -  Spark plug
  12  -  Air filter
  13 -  Starter Handle
 14  -  Choke Lever
  15  -  Throttle trigger lockout
  16  -  STOP button
  17  -  Throttle lever
  18  -  Harness attachment
  19 -  Handle
  20  -  Shaft arm
  21  -  Button half-throttle

4. ASSEMBLY

FITTING THE SAFETY GUARD (Fig.4)

Fit the blade guard (A) to the shaft arm with screws
in a position allowing the operator to work safely (B).

NOTE: use the guard (C) only with nylon head.
Secure the guard (C) to the protection (A) by
means of the screw (D).

FITTING THE NYLON LINE HEAD (Fig. 6)

Put the upper (F) flange in place. Put the head fixing
pin (H)  in the appropriate hole (L) and tighten the
head (N) anti-clockwise by hand.

FITTING THE DISK (Fig. 7)

Fix the blade (R) onto the upper flange (F) making
sure that the rotation direction is correct.
Fix the lower flange (B), the cup (D) and tighten bolt
(A) anti-clockwise.
Put the pin provided in the appropriate hole (L)
to block the blade and allow the bolt (A) to be
tightened to

2.5 kgm (25 Nm).
