Grass trimmer

EasyGrassCut 23

EasyGrassCut 26

No-load speed

min

-1

12500

12500

Cutting line diameter

mm

1.6

1.6

Cutting diameter

cm

23

26

Cutting spool capacity

m

4.0

4.0

Weight according to EPTA‑Proced-
ure 01:2014

kg

2.0

2.0

Protection class

 / II

 / II

Serial number

see type plate on garden tools

The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.

Noise/Vibration Information

3 600 HC1 H..

3 600 HC1 J..

Noise emission values determined according to

EN 50636-2-91

.

Typically the A-weighted noise levels of the product are:

– Sound pressure level

dB(A)

78

80

– Uncertainty K

dB

= 2.5

= 2.5

– Sound power level

dB(A)

90

91

– Uncertainty K

dB

= 2.0

= 1.0

Vibration total values ah (triax vector sum) and uncertainty K determined according to

EN 50636-2-91

– Vibration emission value a

h

m/s

2

< 2.5

< 2.5

– Uncertainty K

m/s

2

= 1.5

= 1.5

Mounting and Operation

Action

Figure

Page

Product features

A

325

Delivery scope

B

326

Removing the transport safety

C

326

Connecting the shaft

D

327

Adjusting the Handle

E

327

Mounting the protection guard

F

328

Connecting the extension cable

Switching On and Off

G

329

Removing the line spool

H

329

Winding line on spool

I

330

Mounting the line spool

J

330

Line feeding

K

331

Maintenance, Cleaning and Stor-
age

L

331

Accessories

M

332

Assembly

u

Caution: Switch the garden tool off and pull the mains
plug before performing any maintenance.

Connect shaft (see figures C and D)

Note:

A connected shaft can no longer be dismounted.

Remove the transport safety

(7)

.

Connect the individual parts of the shaft until they can be
heard to engage.

Mounting and adjusting the handle (see figure E)

The handle

(1)

 can be set to different positions. To change

the adjustment, press buttons

(5)

 and move the handle to

the desired position. Release the buttons

(5)

 again so that

the handle can engage.

Mounting the protection guard (see figure F)

Before mounting the protective guard, pull the plant-protec-
tion frame from the delivery position to the storage position.
Position the protection guard

(6)

 on the trimmer head and

fasten it with the provided screw.

Do not disassemble guard once connected.

Then, pull the plant-protection frame to the working posi-
tion.

Operation

u

Pay attention to the mains voltage.

 The voltage of the

power source must match the voltage specified on the
rating plate of the machine.
