English |

21

Assembly

u

Caution: Switch the garden tool off and pull the mains
plug before performing any maintenance.

Connect shaft (see figures C and D)

Note:

A connected shaft can no longer be dismounted.

Remove the transport safety

(7)

.

Connect the individual parts of the shaft until they can be
heard to engage.

Mounting and adjusting the handle (see figure E)

The handle

(1)

 can be set to different positions. To change

the adjustment, press buttons

(5)

 and move the handle to

the desired position. Release the buttons

(5)

 again so that

the handle can engage.

Mounting the protection guard (see figure F)

Position the protection guard

(6)

 on the trimmer head and

fasten it with the provided screw.

Operation

u

Pay attention to the mains voltage.

 The voltage of the

power source must match the voltage specified on the
rating plate of the machine.

u

Caution: Switch the garden tool off and pull the mains
plug before adjusting or cleaning.

u

The cutting line continues to rotate for a few seconds
after the trimmer is switched off. Allow the motor/cut-
ting line to stop rotating before switching on again.

u

Do not briefly switch off and on again several times in
a row.

u

Only use Bosch approved cutting elements. Cutting
performance will vary with different cutting elements.

Switching On and Off (see figure G)

To

switch on,

 firstly press the lock-off button

(2)

. Then

press the On/Off switch

(3)

 and keep it pressed.

To

switch off,

 release the On/Off switch

(3)

.

Dismounting the spool, winding up the cutting
line and mounting the spool (see figures J to H)

u

Remove the mains plug before replacing the spool.

Press both latches of the spool cover together and remove
the spool cover

(9)

. Afterwards, remove the empty spool

(10)

.

Cut off approx. 4.0 m line from the refill roll. Slide one end of
the cutting line into the hole for line wind-up

(11)

 in the

spool and wind up the cutting line uniformly and tightly.
Slide the other end of the cutting line through the hole for
line guiding

(12)

 in the trimmer head and mount the spool

back into the trimmer head. Affix the spool by mounting the
spool cover .

Line Feeding (see figure K)

Semi-automatic Line Feeding

The trimmer is equipped with a semi-automatic feeding sys-
tem. The system feeds 10 mm of the line with every press of
the on/off switch

(3)

.

Manual Line Feeding

Press the line-feed button

(13)

, and pull the cutting line out

to the desired length.

Troubleshooting

Problem

Possible Cause

Corrective Action

Motor refuses to start

Power turned off

Turn power on

Mains socket faulty

Use another socket

Extension cable damaged

Inspect cable, replace if damaged

Fuse faulty / blown

Replace fuse

Garden tool functions
intermittently

Extension cable damaged

Inspect cable, replace if damaged

Internal wiring of garden tool defective

Contact Bosch customer service agent

Garden product la-
bours

Grass too high

Cut in stages

Garden tool does not
cut

Cutting line too short/broken off

Manually feed cutting line

Spool empty

Replace line spool

Cutting line can no
longer be fed

Line inside the spool entangled

Inspect the spool, rewind if necessary

Spool empty

Refill line spool
