 | English

Technical Data

Grass trimmer

EasyGrassCut 23

EasyGrassCut 26

Article number

3 600 HC1 H..

3 600 HC1 J..

Rated power input

W

280

280

No-load speed

min

-1

12500

12500

Cutting line diameter

mm

1.6

1.6

Cutting diameter

cm

23

26

Cutting spool capacity

m

4.0

4.0

Weight according to EPTA‑Proced-
ure 01:2014

kg

1.9

1.9

Protection class

 / II

 / II

Serial number

see type plate on garden tools

The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.

Noise/Vibration Information

3 600 HC1 H..

3 600 HC1 J..

Noise emission values determined according to

EN 50636-2-91, EN 60745-1:2009

.

Typically the A-weighted noise levels of the product are:

– Sound pressure level

dB(A)

76

79

– Sound power level

dB(A)

90

92

– Uncertainty K

dB

= 1.0

= 1.0

Vibration total values ah (triax vector sum) and uncertainty K determined according to

EN 50636-2-91, EN 60745-1:2009

– Vibration emission value a

h

m/s

2

< 2.5

< 2.5

– Uncertainty K

m/s

2

= 1.5

= 1.5

Mounting and Operation

Action

Figure

Page

Product features

A

323

Delivery scope

B

324

Removing the transport safety

C

324

Connecting the shaft

D

325

Adjusting the Handle

E

325

Mounting the protection guard

F

326

Connecting the extension cable

Switching On and Off

G

326

Removing the line spool

H

327

Winding line on spool

I

327

Mounting the line spool

J

328

Line feeding

K

328

Maintenance, Cleaning and Stor-
age

L

329

Accessories

M

329

Assembly

u

Caution: Switch the garden tool off and pull the mains
plug before performing any maintenance.

Connect shaft (see figures C and D)

Note:

A connected shaft can no longer be dismounted.

Remove the transport safety

(7)

.

Connect the individual parts of the shaft until they can be
heard to engage.

Mounting and adjusting the handle (see figure E)

The handle

(1)

 can be set to different positions. To change

the adjustment, press buttons

(5)

 and move the handle to

the desired position. Release the buttons

(5)

 again so that

the handle can engage.

Mounting the protection guard (see figure F)

Position the protection guard

(6)

 on the trimmer head and

fasten it with the provided screw.
