 English |

17

Bosch Power Tools

F 016 L81 542 | (8.11.16)

Battery Charging



Do not use other battery chargers.

The supplied battery

charger is designed for the Lithium-Ion battery in your gar-
den product.



Observe the mains voltage!

The voltage of the power

supply must correspond with the data given on the name-
plate of the battery charger. Battery chargers marked with
230 V can also be operated with 220 V.

The battery is equipped with temperature monitoring that al-
lows charging only in the temperature range between 0  ° C
and 45  ° C. In this manner, a high battery service life is
achieved.

Note:

The battery supplied is partially charged. To ensure full

capacity of the battery, completely charge the battery in the
battery charger before using your power tool for the first time.

The lithium-ion battery can be charged at any time without re-
ducing its service life. Interrupting the charging procedure
does not damage the battery.

The “Electronic Cell Protection (ECP)” protects the lithium-
ion battery against deep discharging. When the battery is run
down or discharged, the garden product is shut off by means
of a protective circuit: The blade no longer moves.

Do not continue to press the On/Off
switch after the garden product has

been automatically switched off.

The battery can be dam-

aged.

Charging Procedure

The charging procedure starts as soon as the mains plug is
plugged into the socket and the battery is then inserted into
the battery charger.

Due to the intelligent charging method, the charging condi-
tion of the battery is automatically detected and the battery is
charged with the optimum charging current, depending on
battery temperature and voltage.

This gives longer life to the battery and always leaves it fully
charged when kept in the charger for storage.

Note:

The charging procedure is only possible when the bat-

tery temperature is within the allowable charging tempera-
ture range, see section “Technical Data”.

Flashing Battery Charge Indicator

The charging procedure is signalled by a

flashing

 battery charge indicator.

Continuous Lighting of the Battery Charge
Indicator

Continuous lighting

 of the battery

charge indicator  indicates that the
battery is fully charged

or

 that the

temperature of the battery is not with-

in the allowable charging temperature range, and cannot be
charged for this reason. The battery is charged as soon as the
allowable charging temperature range is reached.

When the battery is not inserted,

continuous lighting

 of the

battery charge indicator  indicates that the mains plug is in-
serted in the socket and that the battery charger is ready for
operation.

Charging Advice

With continuous or several repetitive charging cycles without
interruption, the charger can warm up. This is not meaningful
and does not indicate a technical defect of the battery charg-
er.

A significantly reduced working period after charging indi-
cates that the battery is used and must be replaced.

Troubleshooting

d.c.

Problem

Possible Cause

Corrective Action

Blade guard can not be mounted over
cutting disc

Incorrect assembly

Remove cutting disc and mount blade
guard again

Trimmer fails to operate

Battery discharged

Recharge battery; also see “Battery
Charging”

Battery too hot/cold

Allow to cool/warm

Trimmer runs intermittently

Internal wiring of machine damaged

Contact Service Agent

On/Off switch defective

Contact Service Agent

Garden product labours

Grass too high

Cut in stages

Machine does not cut

Cutting blade damaged

Replace the blade

Increased vibration

Cutting blade damaged

Replace the blade
