Mounting the Wheels
(ART 26/2600 ACCUTRIM only)

  Fit the wheels

 11

 onto the shaft

 6

.

  Fit the bolt

 19

 and the wingnut

 18

.

Note:

 The position of the wheels can be adjusted by

loosening the wingnut

 18

 and moving to the desired

position.

  The wheels can be moved up and down the

shaft

 6

 depending on the height of cut required.

Fitting Cutting Disc/Fitting Blade

 Press cutting disc

 20

 onto drive adaptor as

shown (click).

 Fit the blade, place the blade

 22

 over the pivot

 21

and pull outwards until it snaps into place.

 Using Adjustable Handle

The adjustable handle

 4

 can be set in various posi-

tions:

➊

 To change the position undo the handle wing

nut

 3

 and move the adjustable handle

 4

.

➋

 Tighten the handle wing nut

 3

 securely to fix the

adjustable handle

 4

 in the adjusted position.

 Adjusting Product Length

➊

 Loosen the adjustment collar

 5

 90°.

➋

 Pull the shaft out to increase the height, or push

the shaft in to decrease the height. Re-tighten ad-
justment collar

 5

.

 Adjusting cutting head angle:

To change the angle depress the foot pedal

 12

 and

move the shaft

 6

 to the desired position.

Release the foot pedal

 12

.

Adjusting for Edging Mode

 Moving wheels (where fitted):

➊

 Loosen wingnut

 18

.

➋

 Twist wheels

 11 90° as shown.

➌

 Tighten wingnut 18.

 Adjusting cutting head angle:

➊

 Depress the foot pedal 12.

➋

 Move the shaft 6 to the lowest position. Release

the foot pedal 12.

 Move trimmer head:

➊

 Loosen the adjustment collar 5.

➋

 Turn the shaft 6 90° to position the trimmer

head 8 for trimming / edging as shown. Re-tighten
adjustment collar 5.

Remove stones, loose pieces of wood and
other objects from the cutting area.

The blade continues to rotate for a few seconds
after the trimmer is switched off. Allow the mo-
tor/blade to stop rotating before switching “on”
again.
Do not rapidly switch off and on.

Switching On and Off

Press switch 1 and hold depressed. Release
switch 1 for switching off.

 Cutting Grass

Move the trimmer left and right, keeping it well away
from the body.

The trimmer can efficiently cut grass up to a height
of 15 cm. Cut taller grass in stages.

Remove the wheels when cutting long grass
(ART 26/2600 ACCUTRIM only).

 Trimming Edges

Guide the trimmer along the edge of the lawn. Do not
allow the cutting line to contact paved surfaces,
stones or garden walls, since this will wear the blade
rapidly.

  For better control use the plant protector 9

(ART 26/2600 ACCUTRIM only – available as an
accessory for ART 23/2300 ACCUTRIM) as a guide.

  Cutting Around Trees and Bushes

Carefully cut around trees and bushes so that they
do not come into contact with the cutting line.

Plants can die if you damage the bark.

  For better control use adjustable handle 4 and

use the plant protector 9 (ART 26/2600 ACCUTRIM
only – available as an accessory for
ART 23/2300 ACCUTRIM).
